Midwest® P065P
Midwest® GE P065P Non-Fused Pull-Out AC Disconnect Switch, 120/240 VAC, 60 A, 10 hp, 2 Poles
Brand: Midwest®
Item ID: 24015
MPN: P065P
Login for Price
Features
- Pullers are removable or re-installable in the OFF position for user safety during equipment maintenance
- Door has padlock provisions to prevent unauthorized access
- Noryl® thermoplastic enclosure is corrosion resistant and extremely durable, giving long maintenance free service
- 3-piece construction that opens up mounting and wiring areas, reduces installation time
- Numerous knockouts reduce installation time straight-in, straight-out wiring saves time and money
- NF65 fuse block and NF652 puller replacement parts
Description
Midwest® GE AC Disconnect Switch, Non-Fused Pull-Out, 120/240 VAC, 60 A, 10 hp, 1 Phase, 2 Pole, 10 kA Short Circuit, NEMA 3R Enclosure, Surface Mounting, 8 in H x 6 in W x 5-3/4 in D Dimensions, Noryl/Thermoplastic
Specifications
Amperage Rating |
60 A |
Dimensions |
8 in H x 6 in W x 5-3/4 in D |
Enclosure Type |
NEMA 3R |
Horsepower |
10 hp |
Material |
Noryl/Thermoplastic |
Mounting Type |
Surface |
Number of Poles |
2 |
Phase |
1 |
Short Circuit Current Rating |
10 kA |
Type |
Non-Fused Pull-Out |
Voltage Rating |
120/240 VAC |
Standard Approval |
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|cUL/UL Listed |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_cca81372c4af8795a78f5fe0d6d15969e158dd6cfdf33d987660ac0c3b46ff58.pdf
Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_P065P_Full_Engineering_Drawing.pdf
Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ef104849934253e0df89abaa01b8743739a322917a2f7366713d7d3aa2e94ddb.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U065F1_User_Manual.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b31d5043d31e64436daae44b29e0f160bce6175bdebdd5594cb1434cfb136ed6.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_P065P_Specification_Sheet.pdf
Warranty Information 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_fb5b1421de6c499300fa273ee75f7a94cb5ee896c6428a725f16daedbc448603.pdf
Warranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_R101CB2_Warranty.pdf
