Midwest® U065P
Midwest® GE U065P Non-Fused Pull-Out AC Disconnect Switch, 240 VAC, 60 A, 10 hp, 2 Poles
Brand: Midwest®
Item ID: 562438
MPN: U065P
Login for Price
Features
- Pullers are removable or re-installable in the OFF position for user safety during equipment maintenance
- Door has padlock provisions to prevent unauthorized access
- 3-piece construction that opens up mounting and wiring areas, reduces installation time
- Numerous knockouts reduce installation time straight-in, straight-out wiring saves time and money
- Noryl® thermoplastic enclosure is corrosion resistant and extremely durable, giving long maintenance free service
- NF652 puller and FR65 fuse block replacement parts
Description
Midwest® GE AC Disconnect Switch, Non-Fused Pull-Out, 240 VAC, 60 A, 10 hp, 1 Phase, 2 Pole, 10 kA Short Circuit, NEMA 3R Enclosure, Surface Mounting, 7-1/4 in H x 5 in W x 2-1/8 in D Dimensions, Steel, Galvanized/Powder Coated
Specifications
Amperage Rating |
60 A |
Dimensions |
7-1/4 in H x 5 in W x 2-1/8 in D |
Enclosure Type |
NEMA 3R |
Finish |
Galvanized/Powder Coated |
Horsepower |
10 hp |
Material |
Steel |
Mounting Type |
Surface |
Number of Poles |
2 |
Phase |
1 |
Short Circuit Current Rating |
10 kA |
Type |
Non-Fused Pull-Out |
Voltage Rating |
240 VAC |
Standard Approval |
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|cUL/UL Listed |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U010C010_Warranty.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U010C010_Warranty.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U065P010_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U065P010_User_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U065P_Full_Engineering_Drawing.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U065P_Full_Engineering_Drawing.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U065P_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Midwest_U065P_Specification_Sheet.pdf
