Broan® LP50100DC

Broan® LP50100DC LoProfile™ DC Series Oval Duct Ventilation Fan, 50/80/100 cfm, 4 in Dia Duct, 120 V, 0.4 A, 1.2, Import

Brand: Broan®

Item ID: 479541

MPN: LP50100DC

Login for Price

Features

  • Selectable CFM with speeds of 50/80/100 cfm for effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
  • <0.3/0.7/1.2 sones for quiet performance, enough sound to know your fan is on
  • 4 in oval duct connection for installation flexibility, allows for ceiling or wall mounting
  • ENERGY STAR certified efficient operation for lower utility bills
  • UL listed for use over bathtubs and showers when connected to GFCI protected branch circuit
  • Powerful enough for rooms up to 90 sq-ft
  • Brighter white grilles blend in to match most common ceiling paint
  • Brushless DC electronically controlled digital motor is 3X more efficient than standard AC powered ventilation
  • Compatible with RDF2 radiation damper
  • Easy-to-install and/or replace existing product for DIY'ers
  • Quiet operation for a relaxing experience
  • Corrosion-resistant galvanized steel housing withstands moisture

Description

The Broan® LoProfile™ DC (LPDC) Fan is our solution for installations where conventional ventilation simply won't fit. Where multi-family applications require it, the LPDC fan is narrow enough to be installed in a wall between 2 x 4 in studs. It also features selectable cfm, between 50, 80 and 100 cfm.

Broan® Ventilation Fan, Oval Duct, Series: LoProfile™ DC Series, 50/80/100 cfm Flow Rate, 4 in Diameter Duct, 120 V, 0.4 A Current/Amps, 60 Hz Frequency, 1.2, 13 in Grille Length, 14 in Grille Width, Plastic Grille, 10-1/2 in Housing Length, 11-3/8 in Housing Width, 4 in Housing Height, Steel Housing Material, Ceiling Mounting, No Humidity Sensing, No Motion Sensing, White, Import

Specifications

Color

White

Current/Amps

0.4 A

Domestic/Import

Import

Duct Diameter

4 in

Flow Rate

50/80/100 cfm

Frequency Rating

60 Hz

Grille Length

13 in

Grille Material

Plastic

Grille Width

14 in

Housing Height

4 in

Housing Length

10-1/2 in

Housing Material

Steel

Housing Width

11-3/8 in

Humidity Sensing

No

Motion Sensing

No

Mounting Type

Ceiling

Series

LoProfile™ DC Series

Sones

1.2

Type

Oval Duct

Voltage Rating

120 V

Standard Approval

cUL File No. E17814|cULus Listed|ENERGY STAR Certified|HVI-2100 Certified|Title 24 Compliant|UL File No. E17814

Documentation

https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Broan_AE110S_Catalog.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Broan_AE110S_Catalog.pdf

https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Broan_LP50100DC_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Broan_LP50100DC_Manual.pdf

https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Broan_LP50100DC_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Broan_LP50100DC_Specification_Sheet.pdf
