Greengate SP20-RD4
Greengate SP20-RD4 Heavy Duty Switchpack, 2400 to 5400 W Power Rating, 120 to 277 V AC Input, 20 A
Brand: Greengate
Item ID: 488861
MPN: SP20-RD4
Login for Price
Features
- LED ready
- Auto On or manual On
- Fail safe circuitry-in the event of failure, return to close (On)
- Zero-cross circuitry
- Photocell switching ready
- 24 VDC regulated output to sensors
Description
The SP20-RD4 is the latest addition to the Greengate switchpacks family, delivering a wide array of switching solutions in a single unit. This robust switchpack is designed to deliver unmatched performance. The SP20-RD4 features robust and reliable mechanical latching relays, exclusive fail safe circuitry, daylight harvesting, bi-level switching and is configurable for energy code requirements. The switchpack is specifically designed to handle high inrush electronic ballast loads and offer unmatched durability and service.
Greengate Switchpack, Heavy Duty, 2400 to 5400 W Power, 120 to 277 V AC Input, 50/60 Hz Frequency, 20 A, 32 to 122 deg F Operating, 0 to 90% Non-Condensing Humidity, 3.81 in Width, 1.43 in Depth, 2.4 in Height, ABS, White
Specifications
Amperage Rating |
20 A |
Color |
White |
Depth |
1.43 in |
Frequency Rating |
50/60 Hz |
Height |
2.4 in |
Humidity |
0 to 90% Non-Condensing |
Input Voltage |
120 to 277 V AC |
Material |
ABS |
Operating Temperature |
32 to 122 deg F |
Power Rating |
2400 to 5400 W |
Type |
Heavy Duty |
Width |
3.81 in |
Standard Approval |
RoHS Compliant|ECCN: EAR99NLR|UL/cUL Listed|FCC Certified|NOM Certified|NY LL48|IECC Compliant|ASHRAE 90.1|California Title 24 Compliant |
Application |
Lighting, General Purpose Plug Load Control and Indoor Applications |
