Bussmann BBS-5
Bussmann BBS-5 Fast Acting Midget Fuse, 5 A, 600 VAC, 10000 A Interrupt, Class: Supplemental, Cartridge Body
Brand: Bussmann
Item ID: 5950
MPN: BBS-5
Login for Price
Features
- Nickel plated brass end caps
Description
Bussmann Midget Fuse, Fast Acting, Series: BBS, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 5 A, 600 VAC, 10000 A Interrupt, Class: Supplemental, Ferrule Terminal, Holder Mount, Cartridge Body Type, Single Element, Brass/Fiberglass, Black, 13/32 in Dia x 1-3/8 in L Body Size
Specifications
Amperage Rating |
5 A |
Body Size |
13/32 in Dia x 1-3/8 in L |
Body Type |
Cartridge |
Class |
Supplemental |
Color |
Black |
Element |
Single |
Indicating/Non-Indicating |
Non-Indicating |
Interrupt Rating |
10000 A |
Material |
Brass/Fiberglass |
Mounting Type |
Holder |
Rejection/Non-Rejection |
Non-Rejection |
Series |
BBS |
Terminal Type |
Ferrule |
Type |
Fast Acting |
Voltage Rating |
600 VAC |
Standard Approval |
CE Certified|CSA 1422-01|CSA C22.2 No. 248.14|CSA File No. 53787|UL 248-14|UL File No. E19180|UL Guide JDYX |
Application |
Control Circuits, Gaseous Vapor Fixtures, HID Ballasts, Electronic Circuits and Hand Held Meter Applications, Safety and Security Systems |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bussmann_KTS_R_75_Catalog.pdf
Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_91991f3716886aeed589df64dc2234b829e253a1d2883814dbf846d7282472a0.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bussmann_BBS-5_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bussmann_BBS-5_Specification_Sheet.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_919cf7bdc2183a788adab9afdaaa7a1b0717aa06923ce1e023ba886cbe595130.pdf
