EATON BQC250250
EATON BQC250250 Quadplex Type BQC Molded Case Circuit Breaker, 120/240 V AC, 50 A, 10 kA Interrupt, 4 Poles, Thermal Magnetic Trip
Brand: EATON
Item ID: 63609
MPN: BQC250250
Login for Price
Features
- Circuit breaker includes rejection tab and offers long time instantaneous trip to offer superior performance
- Ideal for loadcenter applications and protects wiring from overheating or short-circuits
- Standard interrupting capacity
Description
Eaton’s BR circuit breakers are used in indoor and outdoor BR loadcenters, spa panels, meter breakers and sub panels. They are designed for a wide range of applications such as high short-circuit interrupt, series rating combinations with upstream main breakers, thermal magnetic, AFCI, GFCI, equipment protection and dual function AF/GF.
EATON Molded Case Circuit Breaker, Type BQC, Series: Quadplex, 120/240 V AC, 50 A, 10 kA Interrupt, Thermal Magnetic Trip, 4 Pole, 1 ph, Handle Actuator, Line/Load Lug, 14 to 4 AWG Wire, Plug-On Mount, 60 to 75 deg C, 3 in L x 2 in W x 3 in H
Specifications
Actuator Type |
Handle |
Amperage Rating |
50 A |
Connection Type |
Line/Load Lug |
Dimensions |
3 in L x 2 in W x 3 in H |
Interrupt Rating |
10 kA |
Mounting Type |
Plug-On |
Number of Poles |
4 |
Phase |
1 |
Series |
Quadplex |
Temperature Rating |
60 to 75 deg C |
Trip Type |
Thermal Magnetic |
Type |
Type BQC |
Voltage Rating |
120/240 V AC |
Wire Size |
14 to 4 AWG |
Standard Approval |
CE Certified|cULus 508|Federal Specification W-C-375|UL 489 |
Application |
Conventional Energy Generation, Renewable Energy and Alternative Energy Generation, Marine Vessels and Equipment, Datacenters, IT Space, CI and Hyper Converged, Circuit Protection and Type BR Load Center |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_CH12L3125B_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_CH12L3125B_User_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_BQC250250_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/EATON_BQC250250_Specification_Sheet.pdf
