Bussmann SC-35

• Most economical overcurrent protection solution compared to circuit breakers
• For use in various non-demanding, general purpose applications
• Compact branch circuit units with high interrupt rating and current limitation
• Size rejection by length helps prevent over fusing
• Fuses 7 A and above have a degree of overload time delay that permits them to pass temporary overloads
• 100 kA at 480 VAC, 10 kA at 300 VDC interrupt rating

Bussmann's SC type fuses are UL Class G and provide fast-acting (1/2-6 A) and time-delay (7-60 A) characteristics for circuit protection need. SC fuses are size rejecting in terms of their overall length thereby aiding in the prevention of overfusing

Bussmann Time Delay Fuse, General Purpose Current Limiting, Series: SC Series, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 35 A, 480 VAC, 100000 A/10000 A DC Interrupt, Class: G, 12 s Response, Ferrule Terminal, Holder Mount, Cartridge Body Type, 0.41 in Dia x 2.25 in L Body Size
