EIKO® GBF-FR
EIKO® GBF-FR Aluminized Reflector Halogen Lamp, 20 W, BA15d Double Contact Bayonet, ALR Shape
Brand: EIKO®
Item ID: 446858
MPN: GBF-FR
Login for Price
Features
- Aluminum reflector with frosted front glass
Description
EIKO® Halogen Lamp, Aluminized Reflector, 20 W Wattage, 12 VDC, BA15d Double Contact Bayonet Lamp Base, ALR Shape, 2000 hr Average Life, 3000 K Color Temperature, C-8 Filament, Flood Beam, 32 deg Beam, 1.39 in Dia x 1.63 in L Dimensions
Specifications
Average Life |
2000 hr |
Beam Angle |
32 deg |
Beam Type |
Flood |
Color Temperature |
3000 K |
Dimensions |
1.39 in Dia x 1.63 in L |
Filament |
C-8 |
Lamp Base Type |
BA15d Double Contact Bayonet |
Shape |
ALR |
Type |
Aluminized Reflector |
Voltage Rating |
12 VDC |
Wattage |
20 W |
Standard Approval |
RoHS Compliant |
Application |
For halogen lamp |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_cf7eae476ab606d9f111b270c38e6c4bd3a5531646886f0b382e225a758f0d9c.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_7ba7a1fda04df9188bdbd270304f3abbe64fd9b409262efb113bc518898973fe.pdf
Warranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_47d5dac18fc6e0135c4be3dbd846cd678b45c1550c9c60054c242c5ddffe99c9.pdf
