Electri-Flex 23102
Liquatite® 23102 Type LA Liquid Tight Flexible Metal Conduit With Continuous Bonding Strip, 1 in Trade, 1.041 to 1.066 in ID x 1.29 to 1.315 in OD, 100 ft L, Steel
Brand: Electri-Flex
Item ID: 56
MPN: 23102
Login for Price
Features
- Liquidtight jacket is made of flexible PVC
- Resistant to oils and mild acids
- Flame Retardant
- Sunlight Resistant (UV)
- Marked HD for Heavy-Duty
Description
The flexible inner core is made from a spiral wound strip of heavy gauge, corrosion resistant, hot dipped galvanized steel. The 3/8 through 1-1/4 in trade sizes are squarelock formed and include an integral bonding strip of copper that is enclosed within the convolutions throughout their entire length. The 1-1/2 through 4 in trade sizes are designed with a fully interlocked strip. The liquidtight jacketing material is of a high quality, rugged, flame retardant flexible PVC compound that resists oils, mild acids and exposure to sunlight.
Liquatite® Liquid Tight Flexible Metal Conduit, Type LA, 1 in, 1.041 to 1.066 in Inside Dia, 1.29 to 1.315 in Outside Dia, 100 ft Length, 5-1/2 in Bend Radius, -30 to 80 deg C Dry/60 deg C Wet/70 deg C Oil, Steel, Gray, Hot Dipped Galvanized
Specifications
Bend Radius |
5-1/2 in |
Color |
Gray |
Finish |
Hot Dipped Galvanized |
Inside Diameter |
1.041 to 1.066 in |
Length |
100 ft |
Material |
Steel |
Outside Diameter |
1.29 to 1.315 in |
Temperature Rating |
-30 to 80 deg C Dry/60 deg C Wet/70 deg C Oil |
Trade Size |
1 in |
Type |
Type LA |
Standard Approval |
ARRA Compliant|Buy American Act Compliant|CSA Certified|RoHS Compliant|UL Listed |
Application |
For use in exposed and concealed locations, electric signs and outline lighting over 1000 VAC, marinas and boatyards, elevators and hoistways, fire pumps, pools and fountains |
