diode led® DI-MLV-12V100W
diode led® DI-MLV-12V100W MLV Driver, 12 V Output, 100 W Power Rating, 6.8 in L x 3.1 in W
Brand: diode led®
Item ID: 508567
MPN: DI-MLV-12V100W
Login for Price
Features
- All-purpose dimmable driver for everyday tape light projects
Description
diode led®, DI-MLV-12V100W, Driver, Series: MLV, 12 V Output, 100 W Power, 6.8 in Length, 3.1 in Width, 2.9 in Height, -4 to 158 deg F
Specifications
Height |
2.9 in |
Length |
6.8 in |
Output Voltage |
12 V |
Power Rating |
100 W |
Series |
MLV |
Temperature Rating |
-4 to 158 deg F |
Width |
3.1 in |
Application |
Compatible with many dimmers, on/off switches, Diode LED tape light |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/diode_led_DI_MLV_12V100W_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/diode_led_DI_MLV_12V100W_Instruction_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/diode_led_DI_MLV_12V100W_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/diode_led_DI_MLV_12V100W_Specification_Sheet.pdf
