Acme Electric® T181049
Acme Electric® T181049 Buck Boost Transformer, 120/240 VAC Primary, 12/24 VDC Secondary, 1.51 kVA Power Rating, 50/60 Hz, 1 Phase
Brand: Acme Electric®
Item ID: 502
MPN: T181049
Login for Price
Features
- Epoxy encapsulated
- Wall mounted
- Easily configured for numerous applications
- 5 to 10 times increase in kVA
- Lower cost solution
Description
Acme Electric® Buck Boost Transformer, 120/240 VAC Primary, 12/24 VDC Secondary, 1.51 kVA, 50/60 Hz, 1 ph, 12.52 A at 12 V/6.25 A at 24 V Output Maximum, Wire Lead/Screw, Wall Mount, Class B/130 deg C, NEMA 3R, 115 deg C, 3.67 in L x 3.89 in W x 7.16 in H
Specifications
Connection Type |
Wire Lead/Screw |
Dimensions |
3.67 in L x 3.89 in W x 7.16 in H |
Enclosure Type |
NEMA 3R |
Frequency Rating |
50/60 Hz |
Insulation |
Class B/130 deg C |
Maximum Amperage Rating |
12.52 A at 12 V/6.25 A at 24 V Output |
Mounting Type |
Wall |
Phase |
1 ph |
Power Rating |
1.51 kVA |
Primary Voltage |
120/240 VAC |
Secondary Voltage |
12/24 VDC |
Temperature Rating |
115 deg C |
Standard Approval |
CSA C22.2 No 47|UL 506 |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_858bf27fd1235e458fc6b1dc0c02ef8c2f87f37cd766401fc5ea7d53e2bb3d6f.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_858bf27fd1235e458fc6b1dc0c02ef8c2f87f37cd766401fc5ea7d53e2bb3d6f.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_003fca30ce16fa38378ff5a4b74e025dd721ea28964e23b5b80e4404d7292c14.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_003fca30ce16fa38378ff5a4b74e025dd721ea28964e23b5b80e4404d7292c14.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b93f1db1d6fd250d2470d3af258022615714e442b76bd96c54cd85e6a689f2f7.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b93f1db1d6fd250d2470d3af258022615714e442b76bd96c54cd85e6a689f2f7.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1518582640873.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1518582640873.pdf
