BUCHANAN BTC2/0-14

• Breakaway torque nut snaps off when UL torque requirements are met
• Second nut remains for easy connector removal
• Self-insulated housing eliminates the need for tape
• Safely installs on energized systems
• Grease-filled end cap seals end of conductor for superior weather protection
• Grease-filled boots protect copper teeth from corrosion and prevent arcing
• Hardened copper teeth pierce insulation and bite into conductors

Safe, dependable and easy. The Buchanan B-TAP Insulation Piercing Connector offersa breakaway torque nut that guarantees a perfect connection every time, no moreguesswork. It simply snaps off when UL torque requirements are met. The grease-filledrubber end caps provide superior water and corrosion resistance, while the insulationpiercing design eliminates downtime and power interruptions.That translates into a 60% installed cost savings compared to split bolts. Installation iseasy; all you need is a standard socket or wrench. B-TAP Connectors can be safelyinstalled on energized systems, eliminating power interruptions and downtime.

BUCHANAN B-TAP® Piercing Insulated Tap Connector, Insulation-Piercing, Solid/Stranded Conductor, 4 to 2/0 AWG Main, 14 to 10 AWG Copper Solid/Stranded Tap, 14 to 10 AWG Aluminum Stranded Conductor, 600 V AC, Specifications: 1-Bolt, 2.2 in-lb Torque, 1/2 in Socket, 90 deg C, 1.8 in W x 2.2 in D x 3.1 in H Dimensions
