Intermatic® ETW3CP
Intermatic® ETW3CP 3-Circuit Programmable Smart Wi-Fi Timer, 120 to 277 VAC, 1/2 hp, NO-NC SPST Contact
Brand: Intermatic®
Item ID: 543988
MPN: ETW3CP
Login for Price
Features
- App based configuration and scheduling
- Up to 256 set points or events
- Up to 64 holiday blocks with schedule capabilities
- Automatic input voltage selection
- Local or remote connectivity
- Configurable outputs allow the control of various voltages and applications
- Relays incorporate zero-crossing technology to extend the life of the control
- Non-volatile EEPROM memory protects programming indefinitely
- LED compatible
Description
The ETW Series offers 365 day scheduling, off-site access, and remote ON/OFF control through the easy-to-use Intermatic Connect app.
Intermatic®, ETW3CP, Programmable Smart Wi-Fi Timer, 3-Circuit, Operation Mode: 365 days, 120 to 277 VAC, 1/2 hp, NO-NC SPST Contact Form, 256 On/Off Ratio, CR2032 Lithium Battery, Type 3R Plastic Enclosure, -40 to 158 deg F, Surface Mounting, 7-1/2 in H x 8-7/8 in W x 3 in D Dimensions
Specifications
Battery Type |
CR2032 Lithium |
Contact Form |
NO-NC SPST |
Dimensions |
7-1/2 in H x 8-7/8 in W x 3 in D |
Enclosure Type |
Type 3R Plastic |
Horsepower |
1/2 hp |
Mounting Type |
Surface |
On/Off Ratio |
256 |
Operation Mode |
365 days |
Temperature Rating |
-40 to 158 deg F |
Type |
3-Circuit |
Voltage Rating |
120 to 277 VAC |
Standard Approval |
cULus Listed|RoHS Compliant|PROP65: This product contains lead, known to the State of California to cause cancer and birth defects or other reproductive harm |
Application |
Indoor Lighting Control, Machinery & Pump Controls, Outdoor Lighting Control, Timing/Scheduling ON/OFF |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Intermatic_ETW2CP_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Intermatic_ETW2CP_Instruction_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Intermatic_ETW3CP_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Intermatic_ETW3CP_Specification_Sheet.pdf
