Intermatic® T32404R
Intermatic® T32404R T30000R 1-Phase Mechanical Timer Switch, 24 hr Setting, 240 VAC, 5 hp, DPST/DPST Contact, 2 Poles
Brand: Intermatic®
Item ID: 222835
MPN: T32404R
Login for Price
Features
- Eight breaker spaces
- Reduces installation costs
- Eliminates the need for additional service panels
- Fits most of our hard-wired T100 mechanical and PE digital timers
- Control two-speed pumps with the T30604R
- Fully compatible with all electrical requirements for pool/spa installations
- Load center dead front has two knockouts and one on the side for switches or GFCIs
- Wiring devices may be installed in these load centers with the use of Standoffs, sold separately
Description
Intermatic® Mechanical Timer Switch, 1-Phase, Series: T30000R, 240 VAC, 100 A, 5 hp, 2 Pole, DPST/DPST Contact Form, 24 hr Time Setting, NEMA 3R Enclosure, -40 to 130 deg F, Wall Mounting, 16-1/2 in H x 10-7/8 in W x 4-1/2 in D Dimensions
Specifications
Amperage Rating |
100 A |
Contact Form |
DPST/DPST |
Dimensions |
16-1/2 in H x 10-7/8 in W x 4-1/2 in D |
Enclosure Type |
NEMA 3R |
Horsepower |
5 hp |
Mounting Type |
Wall |
Number of Poles |
2 |
Series |
T30000R |
Temperature Rating |
-40 to 130 deg F |
Time Setting |
24 hr |
Type |
1-Phase |
Voltage Rating |
240 VAC |
Standard Approval |
cCSAus Certified |
Application |
Pool and Spa Equipment Control and Load Center |
Documentation
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_3f72bf5ecefcb004713e2db84222b33da5e294c9703354e11d9cd113be6ac461.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Intermatic_T30401R_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Intermatic_T30401R_Specification_Sheet.pdf
