Legrand® ADTP700RMTUM1

Legrand® Adorne® SofTap™ ADTP700RMTUM1 Through-Universal WI-FI Ready Master Dimmer Switch, 120 VAC, Magnesium

Brand: Legrand®

Item ID: 475066

MPN: ADTP700RMTUM1

Login for Price

Features

  • The sofTap™ Wi-Fi ready master dimmer is a programmable light switch and dimmer combination that pairs with the Adorne® hub to create smart lighting solutions for your home
  • Turn lights On and Off or dim with just the light tap of a finger - or create custom lighting settings to control lights from your smartphone or tablet via the Legrand® lighting control app
  • Compatible with the Google assistant and amazon Alexa
  • Time to install 25 min or less
  • Easily install this master dimmer into an existing electrical box and wire directly to the light
  • Once the master dimmer is installed, a sofTap™ Wi-Fi ready remote dimmer may be installed to allow for Wi-Fi ready control of a light from two locations without rewiring, simply follow the instructions after installing to pair with the master dimmer
  • Innovative snap-in system ensures easy installation
  • This item requires the Adorne® Hub
  • This item requires an Adorne® wallplate
  • This item uses patented Tru-universal technology, enabling the dimmer to support all load types including incandescent/halogen, magnetic low voltage (MLV), electronic low voltage (ELV) in forward or reverse phase, CFL/LED and more.(with the exception of 0 to 10 V LED drivers)
  • Perfect anywhere you'd like to combine Wi-Fi ready lighting control with sensitive sofTap™ technology and the option to dim
  • This Wi-Fi master dimmer is designed with an innovative micro-movement functionality allowing you to turn lights on, off or dim with just a soft "tap"

Description

Legrand® Adorne® SofTap™ WI-FI Ready Master Dimmer Switch, Through-Universal, 120 VAC, 700 W Power, 900 MHz Frequency, CFL/Halogen/Incandescent/LED/MLV Lamp, Surface Mounting, 0 to 50 deg C, Magnesium, 4.20 in L x 1.77 in W x 1.79 in D Dimensions

Specifications

Color

Magnesium

Dimensions

4.20 in L x 1.77 in W x 1.79 in D

Frequency Rating

900 MHz

Lamp Type

CFL/Halogen/Incandescent/LED/MLV

Mounting Type

Surface

Power Rating

700 W

Temperature Rating

0 to 50 deg C

Type

Through-Universal

Voltage Rating

120 VAC

Standard Approval

ARRA Compliant|Buy American Act Compliant|cULus Listed|ECCN: EAR99|FCC Certified|UL 1472

Application

Residential Applications
