RAB BRISK17FA20
RAB BRISK17FA20 Brisk Adjustable Wallpack, (1) Lamps LED Lamp, 19 W Fixture, 120, 208, 240, 277 V, Bronze Housing
Brand: RAB
Item ID: 514806
MPN: BRISK17FA20
Login for Price
Features
- 100,000-Hour LED lifespan
- Integrated 120-277V button photocell
- DLC Premium
- IP65 Rated
Description
RAB, BRISK17FA20, Wallpack, Adjustable, Series: Brisk, 120, 208, 240, 277 V, 19 W Fixture, 0.2, 0.1, 0.08, 0.07 A, LED Lamp, 20 W Lamp, 1 Lamps, 134 Lumens/W Light Output, 100000 hrs Average Life, 3000, 4000, 5000 K Color Temperature, 80 CRI, Constant Current Ballast, 2600, 2921, 2703 Lumens, Class 2 Insulation, IP65 Enclosure, Junction Box Mounting, Die Cast Aluminum Housing Material, Bronze Housing Finish, 8-1/2 in H x 5-11/16 in W x 3 in D Dimensions
Specifications
Amperage Rating |
0.2, 0.1, 0.08, 0.07 A |
Average Life |
100000 hrs |
Ballast Type |
Constant Current |
Color Rendering Index (CRI) |
80 CRI |
Color Temperature |
3000, 4000, 5000 K |
Dimensions |
8-1/2 in H x 5-11/16 in W x 3 in D |
Enclosure Type |
IP65 |
Fixture Wattage |
19 W |
Housing Finish |
Bronze |
Housing Material |
Die Cast Aluminum |
Insulation Type |
Class 2 |
Lamp Type |
LED |
Lamp Wattage |
20 W |
Light Output |
134 Lumens/W |
Lumens |
2600, 2921, 2703 Lumens |
Mounting Type |
Junction Box |
Number of Lamps |
1 |
Series |
Brisk |
Type |
Adjustable |
Voltage Rating |
120, 208, 240, 277 V |
Standard Approval |
UL Listed|BAA Compliant|RoHS-Compliant|DLC Listed|IESNA LM-79 and LM-80|ANSI C78.377-2017 |
Application |
For Wet Locations |
Documentation
Instruction/Installation Manual 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_BRISK17FA20_Installation_Manual.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_Lighting_BRISK17FA20_Instruction_Installation_Manual.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_Lighting_BRISK17FA20_Specification_Sheet.pdf
