RAB Lighting SLIM22-S-30
RAB Lighting SLIM22-S-30 SLIM Wallpacks, LED Lamp, 15.5 to 32.8 W Fixture, 120/208/240/277 V, Bronze Housing
Brand: RAB Lighting
Item ID: 561516
MPN: SLIM22-S-30
Login for Price
Description
LED Tall pack. Covers footprint of most HID Tall packs. Vandal resistant lens. Precision die-cast aluminum. 0-10V dimmable driver with 120-277V photocell.
RAB Lighting, SLIM22-S-30, Wallpacks, Series: SLIM, 120/208/240/277 V, 15.5 to 32.8 W Fixture, 0.28/0.17/0.15/0.13 A, LED Lamp, 30/25/20/15 W Lamp, 135.9 to 158.5 Lumens/W Light Output, 100000 hr Average Life, 3000/4000/5000K K Color Temperature, 83 to 86 CRI, Class 2/Constant Current/0 to 10 V Dimming Ballast, Polycarbonate Lens, 2199 to 4833 Lumens, IP65 Enclosure, Hinged Mounting, Die-Cast Aluminum Housing Material, Bronze Housing Finish, 8 in H x 9-7/16 in W x 4-3/4 in D Dimensions
Specifications
Amperage Rating |
0.28/0.17/0.15/0.13 A |
Average Life |
100000 hr |
Ballast Type |
Class 2/Constant Current/0 to 10 V Dimming |
Color Rendering Index (CRI) |
83 to 86 |
Color Temperature |
3000/4000/5000K K |
Dimensions |
8 in H x 9-7/16 in W x 4-3/4 in D |
Enclosure Type |
IP65 |
Fixture Wattage |
15.5 to 32.8 W |
Housing Finish |
Bronze |
Housing Material |
Die-Cast Aluminum |
Lamp Type |
LED |
Lamp Wattage |
30/25/20/15 W |
Lens Type |
Polycarbonate |
Light Output |
135.9 to 158.5 Lumens/W |
Lumens |
2199 to 4833 Lumens |
Mounting Type |
Hinged |
Series |
SLIM |
Voltage Rating |
120/208/240/277 V |
Standard Approval |
DLC Premium Listed|RoHS Compliant|BAA Compliant|UL Listed|IESNA LM-79 and LM-80|IP65 |
Application |
Suitable for Use in Up to 40 deg C (104 deg F) |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SLIM22_L_150_Catalog.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SLIM22_L_150_Catalog.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SLIM22_L_150_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SLIM22_L_150_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SLIM22_S_30_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SLIM22_S_30_Specification_Sheet.pdf
