RAB RBAY17S
RAB RBAY17S RBA Field-Adjustable High Bay, 130, 100, 80 W, 400 W Incandescent Equivalent, LED Lamp, 12506 to 19432 Lumens
Brand: RAB
Item ID: 524219
MPN: RBAY17S
Login for Price
Features
- 100,000 hr LED lifespan
- 0-10V dimming standard
Description
RAB, RBAY17S, High Bay, Field-Adjustable, Series: RBA, RBAY17S Designation, 130, 100, 80 W Wattage, 400 W Incandescent Equivalent, 120, 208, 240, 277 V, 1.06, 0.83, 0.68, 0.61, 0.48, 0.39, 0.53, 0.42, 0.34, 0.46, 0.36, 0.29 A, LED Lamp, 12506 to 19432 Lumens, 100000 hr Average Life, 82 to 85 CRI, 5000, 4000, 3500 K Color Temperature, 10.24 in H x 1.93 in W x 14.17 in L Dimensions
Specifications
Amperage Rating |
1.06, 0.83, 0.68, 0.61, 0.48, 0.39, 0.53, 0.42, 0.34, 0.46, 0.36, 0.29 A |
Average Life |
100000 hr |
Color Rendering Index (CRI) |
82 to 85 |
Color Temperature |
5000, 4000, 3500 K |
Designation |
RBAY17S |
Dimensions |
10.24 in H x 1.93 in W x 14.17 in L |
Incandescent Equivalent |
400 W |
Lamp Type |
LED |
Lumens |
12506 to 19432 Lumens |
Series |
RBA |
Type |
Field-Adjustable |
Voltage Rating |
120, 208, 240, 277 V |
Wattage |
130, 100, 80 W |
Standard Approval |
DLC Premium Listed|ANSI C78.377-2017|BAA Compliant|RoHS Compliant|UL Listed |
Application |
Suitable for damp locations |
Documentation
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_Lighting_RBAY17L_Installation_Manual.pdf
Instruction/Installation Manual 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_RBAY17S_E_Installation_Manual.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_Lighting_RBAY17L_User_Manual.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_Lighting_RBAY17S_Specification_Sheet.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_RBAY17S_Specification_Sheet.pdf
