RAB SEAL4
RAB SEAL4 SEAL Field-Adjustable LED Vapor Tight, LED Lamp, 120, 208, 240, 277 V
Brand: RAB
Item ID: 524457
MPN: SEAL4
Login for Price
Features
- 0-10V dimming standard
Description
RAB, SEAL4, LED Vapor Tight, Field-Adjustable, Series: SEAL, 120, 208, 240, 277 V, 0.46, 0.26, 0.23, 0.20 A, LED Lamp, 30, 40, 50 W Lamp, 130 to 142 Lumens/W Light Output, 100000 hr Average Life, Warm Neutral Light, 3500 K Color Temperature, 80 CRI, 0 to 10 V Dimmable Ballast, Diffused Polycarbonate Lens, 4080 to 6800 Lumens, NEMA 4X/IP66 Enclosure, V-Hook Mounting, 49.6 in H x 4.5 in W x 3.7 in D Dimensions
Specifications
Amperage Rating |
0.46, 0.26, 0.23, 0.20 A |
Average Life |
100000 hr |
Ballast Type |
0 to 10 V Dimmable |
Color Rendering Index (CRI) |
80 CRI |
Color Temperature |
3500 K |
Dimensions |
49.6 in H x 4.5 in W x 3.7 in D |
Enclosure Type |
NEMA 4X/IP66 |
Housing Material |
Polycarbonate |
Lamp Type |
LED |
Lamp Wattage |
30, 40, 50 W |
Lens Type |
Diffused Polycarbonate |
Light Color |
Warm Neutral |
Light Output |
130 to 142 Lumens/W |
Lumens |
4080 to 6800 Lumens |
Mounting Type |
V-Hook |
Series |
SEAL |
Type |
Field-Adjustable |
Voltage Rating |
120, 208, 240, 277 V |
Standard Approval |
BAA Compliant|ANSI C78.377-2017|DLC 5.1|FCC|Mercury Free|RoHS|IESNA LM-79 and LM-80|NSF Certified|UL 94|UL Listed |
Documentation
Instruction/Installation Manual 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SEAL2_MVS_E_Installation_Manual.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SEAL4_LCBS_MVS_E_Installation_Manual.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_SEAL4_Specification_Sheet.pdf
