NUVO® by SATCO 62/1775
NUVO® by SATCO 62/1775 Surface Fixture, LED Lamp, 47 W Fixture, 120 to 277 VAC
Brand: NUVO® by SATCO
Item ID: 532649
MPN: 62/1775
Login for Price
Description
NUVO® by SATCO, 62/1775, Surface Fixture, 120 to 277 VAC, 47 W Fixture, LED Lamp, 50000 hr Average Life, Warm White/Soft White/Neutral White/Cool White/Natural Light, 2700, 3000, 3500, 4000, 5000 K Color Temperature, 90 CRI, Polymethyl Methacrylate Shade, Dimmable Ballast, 3500 to 4050 Lumens, Surface Mounting, Die Cast Aluminum Housing Material, 1.06 in H x 11.83 in W x 47.72 in L Dimensions
Specifications
Average Life |
50000 hr |
Ballast Type |
Dimmable |
Color Rendering Index (CRI) |
90 |
Color Temperature |
2700, 3000, 3500, 4000, 5000 K |
Dimensions |
1.06 in H x 11.83 in W x 47.72 in L |
Fixture Wattage |
47 W |
Housing Finish |
White |
Housing Material |
Die Cast Aluminum |
Lamp Type |
LED |
Light Color |
Warm White/Soft White/Neutral White/Cool White/Natural Light |
Lumens |
3500 to 4050 Lumens |
Mounting Type |
Surface |
Shade Type |
Polymethyl Methacrylate |
Voltage Rating |
120 to 277 VAC |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nuvo_62_1775_Full_Engineering_Drawing.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nuvo_62_1775_Full_Engineering_Drawing.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nuvo_62_1775_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nuvo_62_1775_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nuvo_62_1775_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Nuvo_62_1775_Specification_Sheet.pdf
