SATCO® S11392
SATCO® S11392 MR Lamp, 4.5 W, 35 W Incandescent Equivalent, GU5.3 Lamp Base, MR16 Shape, 360 Lumens
Brand: SATCO®
Item ID: 576706
MPN: S11392
UPC: 045923113925
Login for Price
Features
- 0.94 Power
- -25 to 45 deg C Operating Temperature
- 60 Hz Operating Frequency
Description
SATCO NUVO's LED MR16 Lamps are a mainstay of accent lighting. Providing focused illumination where it's needed most with spot or flood lighting to highlight the point of attention in retail, hospitality, restaurant, or residential settings. Choose from black or gray housings, and 2700K, 3000K, 3500K, 4000K, and 5000K color temperatures to match the decor and ambiance of any space.
| SATCO S11392 is a dimmable 4.5W MR16 LED lamp with a GU5.3 base for 12V–15V systems. It produces 360 lumens at 3000K with an 80 CRI and 40-degree beam and is rated for use in enclosed fixtures. |
Specifications
Average Life |
25000 hr |
Ballast Type |
Dimmable |
Beam Angle |
40 deg |
Beam Type |
Spread |
Color Rendering Index (CRI) |
80 |
Color Temperature |
3000 K |
Color |
Soft White |
Designation |
4.5MR16/LED/40ft/830/12V |
Dimensions |
1.772 in H x 1.969 in Dia |
Fixture Type |
Enclosed |
Incandescent Equivalent |
35 W |
Lamp Base Type |
GU5.3 |
Lamp Finish |
Gray |
Lumens |
360 Lumens |
Shape |
MR16 |
Type |
MR |
Voltage Rating |
12 V |
Wattage |
4.5 W |
Standard Approval |
cULus Listed|Energy Star|ESID-2405382|ESID-2405382|CA T20|RoHS |
Documentation
SATCO S11392 Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/S11392_Satco_Line_Drawing.pdf
SATCO S11392 Safety Data Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/SATCO_S11392_SDS.pdf
SATCO S11392 Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/SATCO_S11392_Specification_Sheet.pdf
SATCO|NUVO: LED MR16 Lamps Video https://youtu.be/AGv3wXc0L4Q
