Square D™ 150SV43A
Square D™ 150SV43A Dry Buck and Boost Transformer, 120/240 VAC Primary, 12/24 VAC Secondary, 0.15 kVA Power Rating, 60 Hz, 1 ph Phase
Brand: Square D™
Item ID: 36306
MPN: 150SV43A
UPC: 785901876090
Login for Price
Features
- The equipment enclosure is designed and constructed for indoor or outdoor use and is NEMA 3R-rated
- Carry the full load stated on the nameplate isolation transformer
- Can carry loads in excess of their nameplate rating
- Numerous voltage ratios and current ratings can be obtained by varying the connection between the two primary windings and the two secondary windings
- Increased ampacity depends upon the ratio and the voltage to which the transformer is subjected
- Economical, compact means of slightly adjusting an application's voltage up or down
- Gray color
- Powder coated painted steel enclosure
- Sealed and resin filled
Description
XFMR DRY 1PH .15KVA 120X240V-12/24V
Square D™ Buck and Boost Transformer, Dry, 120/240 VAC Primary, 12/24 VAC Secondary, 0.15 kVA Power, 60 Hz Frequency, 1 ph, Wall Mounting, 105 deg C Insulation, NEMA 3R/IP54 Enclosure, 55 deg C, Steel Housing Material, 5 in H x 4.85 in W x 3.75 in D Dimensions
Specifications
Dimensions |
5 in H x 4.85 in W x 3.75 in D |
Enclosure Type |
NEMA 3R/IP54 |
Frequency Rating |
60 Hz |
Housing Material |
Steel |
Insulation |
105 deg C |
Mounting Type |
Wall |
Phase |
1 ph |
Power Rating |
0.15 kVA |
Primary Voltage |
120/240 VAC |
Secondary Voltage |
12/24 VAC |
Temperature Rating |
55 deg C |
Type |
Dry |
Standard Approval |
RoHS Compliant|ECCN: EAR99|CSA Certified|cULus Listed|UL Listed|PROP65: This product can expose you to chemicals including: Phenyl Glycidyl Ether, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov |
Application |
For buck and boost primary use is that the primary and secondary can be interconnected for use as an autotransformer |
