Square D™ 2510KG1B
Square D™ 2510KG1B 1-Phase Type K Single Unit Manual Switch With Handle Guard/Lock-Off, 600/230 VAC/VDC, 30 A, 2 hp at 115/230 VAC/3 hp at 460/575 VAC Power Rating
Brand: Square D™
Item ID: 402138
MPN: 2510KG1B
UPC: 785901554493
Login for Price
Features
- Type K reversing manual switches provide a compact means of starting, stopping and reversing AC motors where overload protection is not required or is provided separately
- Type K two-speed manual switches may be used with separate winding 3 or 1 ph AC motors where overload protection is not required or is provided separately
- Suitable for use with 3-ph squirrel cage motors and for single-phase motors which can be reversed by reconnecting motor leads
- Two switches are used, one to connect the motor for forward rotation and one for reverse
- Two switches are employed to give "on-off" control in each speed
- Economical on/off solution
- Simple design
- Easy to install
- 1/2 and 3/4 in knockouts top and bottom screw clamp
Description
Type K motor starting switches provide manual "On-Off" control of single- or three-phase AC motors, where overload protection is not required or is provided separately. Compact construction and a 600 volt rating make these switches suitable for a wide range of industrial and commercial uses. Typical applications include small machine tools, pumps, fans, conveyors and many other types of electrical machinery. They may also be used on non-motor loads such as resistance heaters.
Square D™ Single Unit Manual Switch, 1-Phase Type K, Series: 2510, 600/230 VAC/VDC, 30 A, 2 hp at 115/230 VAC/3 hp at 460/575 VAC Power, 2 Pole, Non-Reversing Action, Toggle Actuator, Screw Clamp Connection, Red Indicator, NEMA 1 Enclosure, 2.44 in W x 2.75 in D x 4.25 in H Dimensions
Specifications
Action |
Non-Reversing |
Actuator |
Toggle |
Amperage Rating |
30 A |
Connection |
Screw Clamp |
Dimensions |
2.44 in W x 2.75 in D x 4.25 in H |
Enclosure |
NEMA 1 |
Indicator |
Red |
Number of Poles |
2 |
Power Rating |
2 hp at 115/230 VAC/3 hp at 460/575 VAC |
Series |
2510 |
Type |
1-Phase Type K |
Voltage Rating |
600/230 VAC/VDC |
Standard Approval |
CE Certified|CSA LR25490 Class 3211-05|ECCN EAR99|UL File E42243 CCN NLRV Certified|PROP65: This product can expose you to chemicals including: Lead and Lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov |
Application |
Simple Machine Control, HVAC, Self-Protected Motors and 3-ph AC Motors Rated up to 20 hp |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ea2cb5a2b9aa7ea9c1d68c298fb80fe5395c0306f5e831df7594ada8243e9b0d.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b49b95ae0b4e44118e0b340f920a9759784b881ea2d07903e22ac36b421e7090.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510KO2C_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510KO2C_Instruction_Installation_Manual.pdf
Instruction/Installation Manual 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510KW2_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510FF1P_Owners_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510FF1P_Owners_User_Manual.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510MCW13_User_Manual.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510KG1B_RoHS.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510KG1B_Specification_Sheet.pdf
