Square D™ 2510MBG2
Square D™ 2510MBG2 Integral Horsepower Non-Reversing Type M Starter, 3 Poles, NEMA 1/3/M-0 Enclosure
Brand: Square D™
Item ID: 2510MBG2
MPN: 2510MBG2
UPC: 785901792536
Login for Price
Features
- 3 hp at 200 to 230 vac 3-phase, 5 hp at 380 to 575 vac 3-phase, 5 hp 380 to 575 vac 3-phase, 3 hp 200 to 230 vac three-phase
- Painted sheet steel
Description
Manual starter, integral horsepower, NEMA size M0, 3 P, push button control, no pilot light, 600 VAC, NEMA 1 enclosure
Square D™ Starter, Integral Horsepower Non-Reversing Type M, Series: 2510M, 600 VAC, 18 A, 5 hp Motor, 3 Pole, Manual Reset, 3 ph, Pressure Wire Clamp, Thermal Melting Alloy Overload Relay, Pushbutton Control, NEMA 1/3/M-0, Sheet Steel, 5 in W x 4.13 in D x 8.63 in H
Specifications
Amperage Rating |
18 A |
Connection Type |
Pressure Wire Clamp |
Control Type |
Pushbutton |
Dimensions |
5 in W x 4.13 in D x 8.63 in H |
Enclosure Type |
NEMA 1/3/M-0 |
Material |
Sheet Steel |
Motor Power |
5 hp |
Number of Poles |
3 |
Overload Relay |
Thermal Melting Alloy |
Phase |
3 ph |
Reset Type |
Manual |
Series |
2510M |
Type |
Integral Horsepower Non-Reversing Type M |
Voltage Rating |
600 VAC |
Standard Approval |
RoHS Compliant|UL Listed|CSA Certified|ECCN: EAR99|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
Application |
General Purpose and Indoor Applications |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_de1cc1136af9f0cd91ae5c959bb0b9927ece6f953361e76312d1ba004543bd1b.pdf
Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510MCG3_Full_Engineering_Drawing.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510MBW12_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510MBW12_Instruction_Installation_Manual.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510MCW13_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510FF1P_Owners_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510FF1P_Owners_User_Manual.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510MCW13_User_Manual.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Schneider_Electric_XCKN2502P20_RoHS.pdf
RoHS 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_2510MBG2_RoHS.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_046340cf6e21c04fe219f5a1fd52a9648165b5e737feb7a291ddfa5044d5dfb6.pdf
