Schneider Electric 82354 E1 Double Throw General Purpose Non-Fusible Safety Switch, 240 VAC, 250 VDC, 200 A, 15 hp at 240 VAC, TPDT Contact, 3 Poles
Brand: Schneider Electric
Item ID: 82354
MPN: 82354
UPC: 785901453925
Login for Price
Features
- Used for manual transfer of one load between two power sources
- Suitable for use as service entrance equipment
- Quick-make, quick-break operating mechanism
- Visible blade switches for positive "Off" indication
Description
Double throw safety switches are designed to transfer a load from 1-power source to another power source. 30 to 100 A F series switches can be field converted to transfer a power source from 1-load to another.
Schneider Electric Safety Switch, Double Throw General Purpose Non-Fusible, Series: E1, 240 VAC, 250 VDC, 200 A, 15 hp at 240 VAC, 3, 50/60 Hz, 3 Pole, 3 Wires, 200 kA Short Circuit Current, TPDT, NEMA 1/IP67/IK08, Screw Terminal, -25 to 40 deg C, 5.71 in H x 2.81 in W x 2.81 in D, Steel, Gray
Specifications
Amperage Rating |
200 A |
Color |
Gray |
Contact Form |
TPDT |
Dimensions |
5.71 in H x 2.81 in W x 2.81 in D |
Enclosure Type |
NEMA 1/IP67/IK08 |
Frequency Rating |
50/60 Hz |
Horsepower |
15 hp at 240 VAC |
Material |
Steel |
Number of Poles |
3 |
Number of Wires |
3 |
Phase |
3 |
Series |
E1 |
Short Circuit Current Rating |
200 kA |
Temperature Rating |
-25 to 40 deg C |
Terminal Type |
Screw |
Type |
Double Throw General Purpose Non-Fusible |
Voltage Rating |
240 VAC, 250 VDC |
Standard Approval |
RoHS Compliant|IEC 60309-1/60309-2|UL 98|PROP65: This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause Carcinogen & Reproductive harm. For more information go to www.p65warnings.ca.gov |
Application |
Educational, Healthcare, Wastewater, Manufacturing, Mining and Mineral, Residential, Light Commercial, Industrial and Indoor Applications |
