Square D™ 8501KPR13V24 448811
Send

Square D™ 8501KPR13V24

Square D™ 8501KPR13V24 Type K General Purpose Relay With Standard Cover, 10 A, 11 Pin, 3CO/3PDT Contact, 300 VAC/30 VDC V Coil

Brand: Square D™

Item ID: 448811

MPN: 8501KPR13V24

UPC: 785901288152

Login for Price

Add To Cart

Add to Favorites

Features

  • Without test button and LED
  • 1 hp at 277 VAC, 0.33 hp at 120 VAC power rating

Description

Square D™ 8501 K relays are designed for multi-pole switching applications at 240 VAC or lower. These relays have industry standard wiring and pin configurations that allow their use as replacements for many similar relays without wiring or hardware modifications. 10 or 15 A Versions.

Square D™ General Purpose Relay, Type K, Series: 8501K, 10 A, 0.33 hp, 1 hp Power, 300 VAC/30 VDC Coil, 3CO/3PDT Contact Form, 11 Pins, 3 Pole, DIN Rail/Socket Mounting, Octal Pin/Plug-In/Screw Clamp Terminal, IP20/IP40 Enclosure, -40 to 131 deg F, 2.66 in H x 1.4 in W x 1.4 in D Dimensions

Specifications

Amperage Rating

 10 A

Coil Voltage

 300 VAC/30 VDC

Contact Form

 3CO/3PDT

Dimensions

 2.66 in H x 1.4 in W x 1.4 in D

Enclosure Type

 IP20/IP40

Mounting Type

 DIN Rail/Socket

Number of Pins

 11

Number of Poles

 3

Power Rating

 0.33 hp, 1 hp

Series

 8501K

Temperature Rating

 -40 to 131 deg F

Terminal Type

 Octal Pin/Plug-In/Screw Clamp

Type

 Type K

Standard Approval

 RoHS Compliant|REACH Compliant|CE Certified|CSA File No. 260367 Class 3211 07|UL Listed|UL Recognized|cULus File No. E3190 CCN NLDX, NLDX7|cULus File No. E3190 CCN NLDX2/NLDX8 Recognized|IEC 61810-1|Green Premium|PROP65: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov

Application

 Material Handling, Processing, Lighting Control, HVAC/R and Industrial Applications
