Square D™ 8501NR41
Square D™ 8501NR41 Type R Double Tier Relay Socket, 300 VAC, 15 A, For Use With 8501RS(D)41 Relay, 5 Pin
Brand: Square D™
Item ID: 38526
MPN: 8501NR41
UPC: 785901137276
Login for Price
Features
- Spade pin
Description
Square D™ Relay Socket, Type R Double Tier, Series: 8501N, 300 VAC, 15 A, 5 Pins, For Use With: 8501RS(D)41 Relay, DIN Rail/Panel Mounting, Screw Clamp Terminal, 2.875 in W x 0.79 in D x 1.14 in H Dimensions
Specifications
Amperage Rating |
15 A |
Dimensions |
2.875 in W x 0.79 in D x 1.14 in H |
Mounting Type |
DIN Rail/Panel |
Number of Pins |
5 |
Series |
8501N |
Suitable For Use With |
8501RS(D)41 Relay |
Terminal Type |
Screw Clamp |
Type |
Type R Double Tier |
Voltage Rating |
300 VAC |
Standard Approval |
RoHS Compliant|CE Certified|CSA Certified|UL Listed|PROP65: This product can expose you to chemicals including Nickel compounds which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Application |
For use with relays applications |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_00cf55762647f4ec7a83dba7efdfccb504bfa0e8130be106d68d6f52e6ca7672.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Stelpro_AWFA12002C24SW_Manual.pdf
Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b3cfec4e0261e4098d58658b4228a649e56fbdf083df42d22b82b982f20293a4.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Stelpro_AWFA12002C24SW_User_Manual.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8501NR41_RoHS.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_1b68d992afc5f127cb39d96f13d4fce4b297d8aedf62b4871d1a18be74b2d152.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8501NR41_Specification_Sheet.pdf
