Square D™ 8536SBG2V02H30S
Square D™ 8536SBG2V02H30S Type S Starter, 110/120 VAC V Coil, Non-Reversing Action, 3 Poles, NEMA 1 Enclosure
Brand: Square D™
Item ID: 471765
MPN: 8536SBG2V02H30S
UPC: 785901807285
Login for Price
Description
Type S nonreversing magnetic starter, NEMA Size 0, 3 P, 110/120 VAC 50/60 Hz coil, Motor Logic overload, NEMA 1
Square D™ Starter, Type S, 600 VAC, 18 A, 50/60 Hz, 3 hp at 200/230 VAC/5 hp at 460/575 VAC Motor, 110/120 VAC Coil, 3 Pole, Motor Logic™ Solid-State Reset, 3 ph, Screw Clamp, Non-Reversing, Solid-State Overload Relay, NEMA 1, Sheet Steel, 5.55 in W x 5.98 in D x 10 in H
Specifications
Action |
Non-Reversing |
Amperage Rating |
18 A |
Coil Voltage |
110/120 VAC |
Connection Type |
Screw Clamp |
Dimensions |
5.55 in W x 5.98 in D x 10 in H |
Enclosure Type |
NEMA 1 |
Frequency Rating |
50/60 Hz |
Material |
Sheet Steel |
Motor Power |
3 hp at 200/230 VAC/5 hp at 460/575 VAC |
Number of Poles |
3 |
Overload Relay |
Solid-State |
Phase |
3 ph |
Reset Type |
Motor Logic™ Solid State |
Type |
Type S |
Voltage Rating |
600 VAC |
Standard Approval |
CSA Certified|UL Listed|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
Application |
For used full voltage starting and stopping of AC squirrel cage motors applications |
