Square D™ 8536SBO2V02S
Square D™ 8536SBO2V02S Type S Starter, 110/120 VAC V Coil, Non-Reversing Action, 3 Poles, NEMA 0/Open Enclosure
Brand: Square D™
Item ID: 38984
MPN: 8536SBO2V02S
UPC: 785901864639
Login for Price
Description
Square D 8536SBO2V02S non-reversing magnetic starter for motor applications, nema size 0, 5 hp at 600 vac maximum, 18 amperes, 3 pole, with 110/120 VAC, 50/60 Hz operating coil wired for separate source, melting alloy type overload relay, UL Listed, CSA Certified, CE Marked, open style with various types of accessories and enclosures available.
Square D™ Starter, Type S, 600 VAC, 18 A, 50/60 Hz, 3 hp/5 hp Motor, 110/120 VAC Coil, 3 Pole, (3) Thermal Melting Alloy Reset, 3 ph, Screw Clamp, Non-Reversing, Thermal Melting Alloy Overload Relay, NEMA 0/Open, Starting Modes: Magnetic, 3.5 in W x 4.21 in D x 6.77 in H
Specifications
Action |
Non-Reversing |
Amperage Rating |
18 A |
Coil Voltage |
110/120 VAC |
Connection Type |
Screw Clamp |
Dimensions |
3.5 in W x 4.21 in D x 6.77 in H |
Enclosure Type |
NEMA 0/Open |
Frequency Rating |
50/60 Hz |
Motor Power |
3 hp/5 hp |
Number of Poles |
3 |
Overload Relay |
Thermal Melting Alloy |
Phase |
3 ph |
Reset Type |
(3) Thermal Melting Alloy |
Starting Modes |
Magnetic |
Type |
Type S |
Voltage Rating |
600 VAC |
Standard Approval |
UL Listed|CSA Certified|ECCN: EAR99|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
Application |
For full voltage starting and stopping of AC squirrel cage motors applications |
