Square D™ 8536SCG3V08H30S
Square D™ 8536SCG3V08H30S Type S Starter, 208 VAC V Coil, Non-Reversing Action, 3 Poles, NEMA 1 Enclosure
Brand: Square D™
Item ID: 431530
MPN: 8536SCG3V08H30S
UPC: 785901284598
Login for Price
Features
- A normally open holding circuit contact for three wire control is provided as standard
- Sizes 3 to 7 starters use a class 9999 SX6 auxiliary contact as the holding circuit contact
- Class 8536 type S sizes 00 to 6 starters are provided with a melting alloy thermal overload relay as standard
- Three ph starters use three thermal units
Description
Class 8536 type S magnetic starters are used to switch AC inductive motors with a variety of overload relay options. type S NEMA motor starters are designed for operation at 600 VAC max, up to 600 hp and with a max of 810 A.
Square D™ Starter, Type S, 600 VAC, 27 A, 208 VAC Coil, 3 Pole, 3 ph, Screw Clamp Terminal, Non-Reversing, NEMA 1, 152 mm W x 141 mm D x 254 mm H
Specifications
Action |
Non-Reversing |
Amperage Rating |
27 A |
Coil Voltage |
208 VAC |
Connection Type |
Screw Clamp Terminal |
Dimensions |
152 mm W x 141 mm D x 254 mm H |
Enclosure Type |
NEMA 1 |
Number of Poles |
3 |
Phase |
3 ph |
Type |
Type S |
Voltage Rating |
600 VAC |
Standard Approval |
CSA Certified|REACH Compliant|UL Listed|PROP65: This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_76f7096983aa37dcb5e82228503d8b7cb1c9d9eb24231fad3b5edd9829fd222d.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b8762c86d220b0515e8eccb9e19a262561973f5e68d4bef9b620f1ac472efce4.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8536SCO3V02H318S_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8536SCO3V02H318S_Instruction_Installation_Manual.pdf
Instruction/Installation Manual 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8940SSC4010V02S_Installation_Manual.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8536SAG12V02CS_User_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8536SDO1V02H301S_Owners_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8536SDO1V02H301S_Owners_User_Manual.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_2c155b55c4bd3bde8a4dcf192a0436e959c3aa573d5a88480844099bed28de0c.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8536SCG3V08H30S_Specification_Sheet.pdf
