Square D™ 8903LG80V02 39704
Send

Square D™ 8903LG80V02

Square D™ 8903LG80V02 Type L Electrically Held Multi-Pole Lighting Contactor, 110/120 VAC V Coil, 30 A, 8NO Contact, 8 Poles

Brand: Square D™

Item ID: 39704

MPN: 8903LG80V02

UPC: 785901851516

Login for Price

Add To Cart

Add to Favorites

Features

  • 30 A ballast lighting rating, 20 A tungsten lighting rating
  • 2 thru 12-pole versions
  • Field convertible contacts with no and NC indicators
  • Without indicator

Description

Square D™ Lighting Contactor, Type L Electrically Held Multi-Pole, Series: 8903L, 110/120 VAC Coil, 30 A Maximum Load Current, 35 VA Coil, 8 Pole, 50/60 Hz, 8NO, Screw Clamp, NEMA 1, Surface Mount, 7.81 in W x 6.03 in D x 12.69 in H

Specifications

Coil Power Rating

 35 VA

Coil Voltage

 110/120 VAC

Connection Type

 Screw Clamp

Contact Configuration

 8NO

Dimensions

 7.81 in W x 6.03 in D x 12.69 in H

Enclosure Type

 NEMA 1

Frequency Rating

 50/60 Hz

Maximum Load Current

 30 A

Mounting Type

 Surface

Number of Poles

 8

Series

 8903L

Type

 Type L Electrically Held Multi-Pole

Standard Approval

 RoHS Compliant|UL File No. E78427|CCN Guide No. NRNT|CSA File No. LR60905 Certified|Class 3211-07

Documentation

Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_81b04be955fef344d0d088efc3fe13365bbf03400fe1a7097c1a7bc130bf9609.pdf

https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903L1R_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903L1R_Instruction_Installation_Manual.pdf

Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903LO0012V02_Installation_Manual.pdf

RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903LG80V02_RoHS.pdf

Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ad01ff9070e7ce99c4adbf5ba6fb6c7a138465d006cc52e26698aaeb36e748c9.pdf

Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903LG80V02_Specification_Sheet.pdf

videoVIDEO LINK https://www.youtube.com/embed/cPMJNL-eQdk
