Square D™ 8903LO80V02
Square D™ 8903LO80V02 Type L Electrically Held Multi-Pole Lighting Contactor, 110/120 VAC V Coil, 30 A, 8NO Contact, 8 Poles
Brand: Square D™
Item ID: 425018
MPN: 8903LO80V02
UPC: 785901851738
Login for Price
Features
- 30 A ballast lighting rating, 20 A tungsten lighting rating
- 2 thru 12-pole versions
- Field convertible contacts with no and NC indicators
- Without indicator
Description
Square D™ Lighting Contactor, Type L Electrically Held Multi-Pole, Series: 8903L, 110/120 VAC Coil, 30 A Maximum Load Current, 8 Pole, 50/60 Hz Frequency, 8NO Contact Configuration, Screw Clamp Connection, Open Enclosure, Surface Mounting, 2.88 in W x 3.12 in D x 5 in H Dimensions
Specifications
Coil Voltage |
110/120 VAC |
Connection Type |
Screw Clamp |
Contact Configuration |
8NO |
Dimensions |
2.88 in W x 3.12 in D x 5 in H |
Enclosure Type |
Open |
Frequency Rating |
50/60 Hz |
Maximum Load Current |
30 A |
Mounting Type |
Surface |
Number of Poles |
8 |
Series |
8903L |
Type |
Type L Electrically Held Multi-Pole |
Standard Approval |
RoHS Compliant|UL File No. E78427|CCN Guide No. NRNT|CSA File No. LR60905 Certified|Class 3211-07 |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903L1R_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903L1R_Instruction_Installation_Manual.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903LO0012V02_Installation_Manual.pdf
RoHS 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Schneider_Electric_ZCMD29C12_RoHS.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903LO80V02_RoHS.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_bf1d8e55c99fb00d7e9582d12f49739fe1c2bf39ef65059b601a71c0da639b3b.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8903LO80V02_Specification_Sheet.pdf
