Square D™ 8910DPA32V09
Square D™ 8910DPA32V09 Type DPA 1-Phase Electromechanical Definite Purpose Contactor, 208/220/240 VAC V Coil, 30 A, 2NO Contact, 2 Poles
Brand: Square D™
Item ID: 535123
MPN: 8910DPA32V09
UPC: 785901749813
Login for Price
Features
- Quick-connect terminals and binder head screws allow for easy wiring
- Auxiliary contact modules snap-on either side of the type DPA contactors
- Compact Design
- Low Coil VA
- Straight-Through Wiring
- Continuous Duty Cycle
- Low Cost
Description
Square D™ 8910DPA32V09 magnetic contactor, definite purpose, for heating, air conditioning and refrigeration applications, 2-pole, 30 a (inductive) and 40 a (resistive) maximum at 600 V, 208 to 240 VAC, 50/60 Hz. Operating coil, UL recognized, CSA Certified, CE marked, open style, with type 1 enclosure and DIN mounting bracket available.
Square D™ Definite Purpose Contactor, Type DPA 1-Phase Electromechanical, Series: 8910, 208/220/240 VAC Coil, 30 A Maximum Load Current, Coil Power Rating: 2 hp at 115 VAC/5 hp at 230 VAC, 2 Pole, 50/60 Hz, Non-Reversing Contact, 2NO, 600 VAC Contact, Binding Head Screw, Quick-Connect Terminal, Open, 500000 cycles Mechanical/200000 cycles Electrical cycles Operating Cycles, 32 to 149 deg F Operating, DIN Track/Panel Mount, 2.5 in W x 3.12 in D x 4 in H
Specifications
Coil Power Rating |
2 hp at 115 VAC/5 hp at 230 VAC |
Coil Voltage |
208/220/240 VAC |
Connection Type |
Binding Head Screw |
Contact Configuration |
2NO |
Contact Rating |
600 VAC |
Contact Type |
Non-Reversing |
Dimensions |
2.5 in W x 3.12 in D x 4 in H |
Enclosure Type |
Open |
Frequency Rating |
50/60 Hz |
Maximum Load Current |
30 A |
Mounting Type |
DIN Track/Panel |
Number of Poles |
2 |
Operating Cycles |
500000 cycles Mechanical/200000 cycles Electrical cycles |
Operating Temperature |
32 to 149 deg F |
Series |
8910 |
Terminal Type |
Quick-Connect |
Type |
Type DPA 1-Phase Electromechanical |
Standard Approval |
CCN Guide No. NLDX2|CE Certified|CSA File No. LR25490/Class 3211-04|RoHS Compliant|UL File No. E3190|UL Recognized|PROP65: Cancer and Reproductive harm - www.P65Warnings.ca.gov |
Application |
Heating, Air Conditioning, Refrigeration, Data Processing and Food Service Equipment Applications |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b1dc11d61d362f322f1ebab7d145275826a97be7c81d4cb207bb2cd710c03152.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA33V02_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA92V02_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA92V02_Instruction_Installation_Manual.pdf
Instruction/Installation Manual 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_H222N_Manual.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA32V09_RoHS.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_8231ba652868575bb6a7f929d77a18ae5d208f03de77f06f32f1aa16131c1450.pdf
