Square D™ 8910DPA53V09
Square D™ 8910DPA53V09 3-Phase Electromechanical Type DPA Definite Purpose Contactor, 208/220/240 VAC V Coil, 50 A, 3NO Contact, 3 Poles
Brand: Square D™
Item ID: 40053
MPN: 8910DPA53V09
UPC: 785901080732
Login for Price
Features
- Quick-connect terminals and binder head screws allow for easy wiring
- Auxiliary contact modules snap-on either side of the type DPA contactors
- Compact Design
- Low Coil VA
- Straight-Through Wiring
- Continuous Duty Cycle
- Low Cost
Description
Square D™ 8910DPA53V09 magnetic contactor, definite purpose, for heating, air conditioning and refrigeration applications, 3-pole, 50 a (inductive) and 65 a (resistive) maximum at 600 V, 208 to 240 VAC, 50/60 Hz. Operating coil, UL recognized, CSA Certified, CE marked, open style, with type 1 enclosure and DIN mounting bracket available.
Square D™ Definite Purpose Contactor, 3-Phase Electromechanical Type DPA, Series: 8910, 208/220/240 VAC Coil, 50 A Maximum Load Current, Coil Power Rating: 3 hp at 115 VAC/10 hp at 230 VAC/15 hp at 230 VAC/30 hp 460/575 VAC, 3 Pole, 50/60 Hz, Non-Reversing Contact, 3NO, 600 VAC Contact, Binding Head Screw, Quick-Connect Terminal, Open, 500000 cycles Mechanical/200000 cycles Electrical cycles Operating Cycles, 32 to 149 deg F Operating, DIN Track/Panel Mount, 2.56 in W x 3.67 in D x 4.06 in H
Specifications
Coil Power Rating |
3 hp at 115 VAC/10 hp at 230 VAC/15 hp at 230 VAC/30 hp 460/575 VAC |
Coil Voltage |
208/220/240 VAC |
Connection Type |
Binding Head Screw |
Contact Configuration |
3NO |
Contact Rating |
600 VAC |
Contact Type |
Non-Reversing |
Dimensions |
2.56 in W x 3.67 in D x 4.06 in H |
Enclosure Type |
Open |
Frequency Rating |
50/60 Hz |
Maximum Load Current |
50 A |
Mounting Type |
DIN Track/Panel |
Number of Poles |
3 |
Operating Cycles |
500000 cycles Mechanical/200000 cycles Electrical cycles |
Operating Temperature |
32 to 149 deg F |
Series |
8910 |
Terminal Type |
Quick-Connect |
Type |
3-Phase Electromechanical Type DPA |
Standard Approval |
CCN Guide No. NLDX2|CE Certified|CSA File No. LR25490/Class 3211-04|RoHS Compliant|UL File No. E3190|UL Recognized|PROP65: Cancer and Reproductive harm - www.P65Warnings.ca.gov |
Application |
Heating, Air Conditioning, Refrigeration, Data Processing and Food Service Equipment Applications |
Documentation
Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA63V02_Full_Engineering_Drawing.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9998DA2V02_Full_Engineering_Drawing.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9998DA2V02_Full_Engineering_Drawing.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA33V02_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA92V02_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA92V02_Instruction_Installation_Manual.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA53V09_RoHS.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_0732ea42d4876316504abe41ec5b1a05e754c6bbaf8c9e1480150e6b259a4ad3.pdf
Warranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_9917ac4648c86be7cd659fc5a55b070a4c84ff7521892cfcfcca7d69b9904554.pdf
