Square D™ 8910DPA53V14
Square D™ 8910DPA53V14 3-Phase Electromechanical Type DPA Definite Purpose Contactor, 24 VAC V Coil, 50 A, 3NO Contact, 3 Poles
Brand: Square D™
Item ID: 40055
MPN: 8910DPA53V14
UPC: 785901080770
Login for Price
Features
- Quick-connect terminals and binder head screws allow for easy wiring
- Auxiliary contact modules snap-on either side of the type DPA contactors
- Compact Design
- Low Coil VA
- Straight-Through Wiring
- Continuous Duty Cycle
- Low Cost
Description
Square D™ 8910DPA53V14 magnetic contactor, definite purpose, for heating, air conditioning and refrigeration applications, 3-pole, 50 a (inductive) and 65 a (resistive) maximum at 600 V, 24 VAC, 50/60 Hz. Operating coil, UL recognized, CSA Certified, CE marked, open style, with type 1 enclosure and DIN mounting bracket available.
Square D™ Definite Purpose Contactor, 3-Phase Electromechanical Type DPA, Series: 8910, 24 VAC Coil, 50 A Maximum Load Current, Coil Power Rating: 3 hp at 115 VAC/10 hp at 230 VAC/15 hp at 230 VAC/30 hp 460/575 VAC, 3 Pole, 50/60 Hz, Non-Reversing Contact, 3NO, 600 VAC Contact, Binding Head Screw, Quick-Connect Terminal, Open, 500000 cycles Mechanical/200000 cycles Electrical cycles Operating Cycles, 32 to 149 deg F Operating, DIN Track/Panel Mount, 2.56 in W x 3.67 in D x 4.06 in H
Specifications
Coil Power Rating |
3 hp at 115 VAC/10 hp at 230 VAC/15 hp at 230 VAC/30 hp 460/575 VAC |
Coil Voltage |
24 VAC |
Connection Type |
Binding Head Screw |
Contact Configuration |
3NO |
Contact Rating |
600 VAC |
Contact Type |
Non-Reversing |
Dimensions |
2.56 in W x 3.67 in D x 4.06 in H |
Enclosure Type |
Open |
Frequency Rating |
50/60 Hz |
Maximum Load Current |
50 A |
Mounting Type |
DIN Track/Panel |
Number of Poles |
3 |
Operating Cycles |
500000 cycles Mechanical/200000 cycles Electrical cycles |
Operating Temperature |
32 to 149 deg F |
Series |
8910 |
Terminal Type |
Quick-Connect |
Type |
3-Phase Electromechanical Type DPA |
Standard Approval |
CCN Guide No. NLDX2|CE Certified|CSA File No. LR25490/Class 3211-04|RoHS Compliant|UL File No. E3190|UL Recognized|PROP65: Cancer and Reproductive harm - www.P65Warnings.ca.gov |
Application |
Heating, Air Conditioning, Refrigeration, Data Processing and Food Service Equipment Applications |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_bdc7bedba74f0d5c0adfda0353e9c1fb6378d85c570bbd53eecda84934cae3b0.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA53V14_Full_Engineering_Drawing.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA53V14_Full_Engineering_Drawing.pdf
Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA53V14_RoHS.pdf
Full Engineering Drawing 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA63V02_Full_Engineering_Drawing.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9998DA2V02_Full_Engineering_Drawing.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9998DA2V02_Full_Engineering_Drawing.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA33V02_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA92V02_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8910DPA92V02_Instruction_Installation_Manual.pdf
Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ca41e2a3b65dd3f72ed1db9769ff970af4bd6f86d273281d5bc06eb472f9994e.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_87883c5a848cfb270254b5ed4af499506c1437a9c22f0089bbda084bc8c21bd6.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Schneider_Electric_BMXDAI1604H_RoHS.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_d77e354a7adfaf5b085f1f068fb24121453a7975fce148f3bb29100f1d4721ac.pdf
