Square D™ 8911DPSO13V02
Square D™ 8911DPSO13V02 Type DPS Definite Purpose Starter, 110/120 VAC V Coil, Non-Reversing Action, 3 Poles, Open Enclosure
Brand: Square D™
Item ID: 474253
MPN: 8911DPSO13V02
UPC: 785901116752
Login for Price
Features
- 3 hp 230 vac 1 ph, 7.5 hp 230/460/575 vac 3 ph, 1.5 hp 115 vac 1 ph rated power
Description
Square D™ Definite Purpose Starter, Type DPS, Series: 8911, 600 VAC, 20 A, 50/60 Hz Frequency, 3 hp at 115 VAC, 7-1/2 hp at 460/575 VAC Motor, 110/120 VAC Coil, 3 Pole, Thermal Melting Alloy Reset, 3 ph, Non-Reversing Action, Open Enclosure
Specifications
Action |
Non-Reversing |
Amperage Rating |
20 A |
Coil Voltage |
110/120 VAC |
Enclosure Type |
Open |
Frequency Rating |
50/60 Hz |
Motor Power |
3 hp at 115 VAC, 7-1/2 hp at 460/575 VAC |
Number of Poles |
3 |
Phase |
3 |
Reset Type |
Thermal Melting Alloy |
Series |
8911 |
Type |
Type DPS |
Voltage Rating |
600 VAC |
Standard Approval |
RoHS Compliant|REACH Compliant|ECCN: EAR99|PROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_36d97e997ae4e07eee35d8ff9bd187904f6a02d0efec182bbf2b4b8f45a1d444.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8911DPSO13V02_RoHS.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_72f580879565ff59480b53bd0ee14e53f16179a9bf14bf0f59ba01b1169831ae.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_8911DPSO13V02_Specification_Sheet.pdf
