Square D™ 9013FSG2J24M1
Square D™ Pumptrol™ 9013FSG2J24M1 Type F Electromechanical Pressure Switch, 10 to 45 psig Pressure, 2NC/DPST-DB Contact, Screw Clamp Connection
Brand: Square D™
Item ID: 521868
MPN: 9013FSG2J24M1
UPC: 785901320418
Login for Price
Features
- 9013F power pressure switches rated for the direct control of motors in pump and compressor applications
- Rugged, robust construction provides a long life and provides years of uninterrupted, worry-free service
- Drift proof cut-in and cut-out settings
- Has visible vertical contacts, easy to inspect without removal
- An extra strong frame that resists distortion when mounting the switch to a compressor
- Designed for the direct control of motors in pump and compressor applications
- 1/4 in NPSF Internal pressure
- 40 to 60 psi pressure
- Adjustable differential <= 1.5 hp, standard action
- Maintained manual cut-out lever (auto-off) FSG, FYG
Description
Pressure switches, float switches, vacuum switches and power pressure switches for control or monitoring of water pumps, compressors, agricultural/irrigation water systems, moulding presses, injection moulders, grinding machines, machining centers, complex and special machines, HVAC, automotive, food and beverage, healthcare facilities, pharmaceutical and more. Classes 9013.
Square D™ Pumptrol™ Electromechanical Pressure Switch, Type F, Series: 9013, 10 to 45 psig Pressure, 2NC/DPST-DB Contact Configuration, 10 cpm Operating Cycles, -33 to 257 deg F, Screw Clamp Connection, Zinc Plated Steel Connection, Nitrile Diaphragm, Polypropylene Housing Material, IP20/NEMA 1 Enclosure
Specifications
Connection Material |
Zinc Plated Steel |
Connection Type |
Screw Clamp |
Contact Configuration |
2NC/DPST-DB |
Diaphragm Material |
Nitrile |
Enclosure Type |
IP20/NEMA 1 |
Housing Material |
Polypropylene |
Operating Cycles |
10 cpm |
Pressure Rating |
10 to 45 psig |
Series |
9013 |
Temperature Rating |
-33 to 257 deg F |
Type |
Type F |
Standard Approval |
ECCN: EAR99|CE Certified|CSA File LR25490|IEC 60529|REACH Compliant|RoHS Compliant|UL 50/508/File E12158|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other Reproductive harm. For more information go to www.P65Warnings.ca.gov |
Application |
Industrial, Pressure control or monitoring of water pumps, compressors, agricultural/irrigation water systems, moulding presses, injection moulders, grinding machines, machining centers, complex and special machines, HVAC, automotive, food and beverage, healthcare facilities, pharmaceutical and Control electrically driven water pumps |
