Square D™ 9037HG32L
Square D™ 9037HG32L Type H Float Switch, 575 VAC
Brand: Square D™
Item ID: 428843
MPN: 9037HG32L
UPC: 785901075639
Login for Price
Features
- A complete line of switches designed for open or closed tank applications they detect rising or falling liquid levels in various types of containers
- Float movement is transmitted through a quad ring seal
- Standard (contacts close on liquid rise)
- 6 to 11-1/2 in adjustable float moment
- Liquid level control
Description
The Class 9037 Type H switches are attached to the tank by means of a 2-1/2 in bushing. An external pointer indicates the float position within the tank when the unit is mounted. Switches come complete with stainless steel float and rod. A nitrile rubber seal, such as a Buna-N quad ring seal, is used between the float rod and the sealing connector. Normal application is at atmospheric pressure. Where higher pressures are encountered, the available FKM® seal allows the switch to withstand tank pressures up to 50 psi at ambient temperatures up to 220 deg F. Occasional replacement of the quad ring seal may be necessary.
Square D™ Float Switch, Type H, Series: 9037, 575 VAC, Screw Clamp, NEMA 1, -22 to 220 deg F Operating, Screw-In Bushing Mount
Specifications
Connection Type |
Screw Clamp |
Enclosure Type |
NEMA 1 |
Mounting Type |
Screw-In Bushing |
Operating Temperature |
-22 to 220 deg F |
Series |
9037 |
Type |
Type H |
Voltage Rating |
575 VAC |
Standard Approval |
ECCN EAR99|CE Certified|CSA File LR25490|REACh Compliant|UL 50/508/File E12158|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov |
Application |
Closed Tank Application |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_LOT2T65_D10_Brochure.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9037HG32L_Catalog.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9037HG32L_Catalog.pdf
Catalog 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9037HG32L_Specification_Sheet.pdf
Instruction/Installation Manual 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_LOT2T65_D10_Installation_Sheet.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9037HG30R_Installation_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9037HG36F3LZ20_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9037HG36F3LZ20_Instruction_Installation_Manual.pdf
Line Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/RAB_LOT2T65D10_Line_Drawing.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9012GAW5K_User_Manual.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9038CG36N4LZ20_Owners_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9038CG36N4LZ20_Owners_User_Manual.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b1c1e6a9c9766c476078e75cabe420a2188591c7f6469a961c12cf94141acd12.pdf
Warranty Information https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_9917ac4648c86be7cd659fc5a55b070a4c84ff7521892cfcfcca7d69b9904554.pdf
