Square D™ 9065SF020
Square D™ 9065SF020 Solid-State Thermal Overload Relay, 18 A
Brand: Square D™
Item ID: 537734
MPN: 9065SF020
UPC: 785901749929
Login for Price
Features
- Switch selectable trip class
- Class II ground fault detection
- Direct replacement for type s melting alloy
Description
Square D™ Thermal Overload Relay, Solid-State, 18 A, 50/60 Hz Frequency, 18 A at 600 VAC Contact, 3 Pole, Surface Mounting, NEMA 0 Enclosure, 6.1 in W x 5.3 in D x 5.5 in H Dimensions
Specifications
Amperage Rating |
18 A |
Contact Rating |
18 A at 600 VAC |
Dimensions |
6.1 in W x 5.3 in D x 5.5 in H |
Enclosure Type |
NEMA 0 |
Frequency Rating |
50/60 Hz |
Mounting Type |
Surface |
Number of Poles |
3 |
Type |
Solid-State |
Standard Approval |
RoHS Compliant|CE/CSA/NOM Certified|UL Listed|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
