Square D™ 9070T500D13
Square D™ 9070T500D13 Industrial Control Transformer, 120 VAC Primary, 12/24 VAC Secondary, 500 VA Power Rating, 50/60 Hz, 1 ph Phase
Brand: Square D™
Item ID: 512869
MPN: 9070T500D13
UPC: 785901905363
Login for Price
Features
- Designed with low impedance windings for excellent voltage regulation
- Can accommodate the high inrush current associated with contactor, starters, solenoid and relays
- Comes with unmatched design innovations for top performance
- Manufactured using the most advanced insulating material and is best choice if size and cost are of concern
- Copper winding
Description
The type T units are designed for the global market and are the best choice when size and cost are of concern. This is our most popular and complete offering of industrial control transformers.
Square D™, 9070T500D13, Industrial Control Transformer, 120 VAC Primary, 12/24 VAC Secondary, 500 VA Power, 50/60 Hz Frequency, 1 ph, Screw Clamp Connection, Panel Mounting, 115 deg C Rise Insulation, Open Enclosure, 115 deg C, 4.5 in W x 5.49 in D x 3.84 in H Dimensions
Specifications
Connection Type |
Screw Clamp |
Dimensions |
4.5 in W x 5.49 in D x 3.84 in H |
Enclosure Type |
Open |
Frequency Rating |
50/60 Hz |
Insulation |
115 deg C Rise |
Mounting Type |
Panel |
Phase |
1 ph |
Power Rating |
500 VA |
Primary Voltage |
120 VAC |
Secondary Voltage |
12/24 VAC |
Temperature Rating |
115 deg C |
Type |
Type T |
Standard Approval |
RoHS Compliant|ECCN: EAR99|CE Certified|CSA File No. LR37055 Guide 184-N-90|UL File No. E61239|PROP65: This product can expose you to chemicals including: Phenyl Glycidyl ether, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov|NOM Certified |
Application |
For handling high inrush associated with contactors, relays, conveyor systems, paint lines, punch presses or overhead cranes and FSC1 fingersafe cover |
