Square D™ 9080GM6B
Square D™ 9080GM6B Terminal Block End Barrier, 600 VAC, 60 A, Natural
Brand: Square D™
Item ID: 46230
MPN: 9080GM6B
UPC: 785901744023
Login for Price
Features
- 35 mm din rail 3, 9080GH track mounting
Description
Square D™ Terminal Block End Barrier, Series: 9080G, 600 VAC, 60 A, DIN Rail Mount, 40 to 221 deg F, Polyamide, Natural, 2.3 in L x 2 in W
Specifications
Amperage Rating |
60 A |
Color |
Natural |
Dimensions |
2.3 in L x 2 in W |
Material |
Polyamide |
Mounting Type |
DIN Rail |
Series |
9080G |
Temperature Rating |
40 to 221 deg F |
Voltage Rating |
600 VAC |
Standard Approval |
RoHS Compliant|UL Listed|CSA Certified|CE Certified|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
Application |
For GK6 NEMA type terminal block applications |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/AFC_Cable_Systems_1901_42_00_Catalog.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9080GMR6B_Instruction_Installation_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9080GMR6B_Instruction_Installation_Manual.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9080GMY6B_Installation_Manual.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9080GM6B_RoHS.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_94a96a9ccb8960dca9575fe8c930e9c30deba1b72b634b584623792364897c8a.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_9080GM6B_Specification_Sheet.pdf
