Square D™ AL800P6K 3-Pole Mechanical Lug Kit, 3/0 AWG to 600 kcmil, Surface Mount, For Use With 800 to 1200 A PG, PJ, PL, MG, MJ Frame Circuit Breaker
Brand: Square D™
Item ID: 483894
MPN: AL800P6K
UPC: 785901409533
Login for Price
Features
- Downstream location of connection
- HVAC
- Control Equipment Panels
- Automotive
- Conveyance Lines
Description
The M-frame, P-frame and NS630b-NS1250 circuit breakers have mechanical lugs standard on both ends of the unit-mounted circuit breakers. The M-frame and P-frame I-Line™ circuit breakers have mechanical lugs standard on the ON/OFF end only. These lugs are suitable for use with copper or aluminum wire. Rear connectors, compression lugs and distribution lugs are available for special applications. These lugs are certified to UL, IEC and CSA Standards.
Square D™ Mechanical Lug Kit, 3-Pole, 3/0 AWG to 600 kcmil Conductor, Surface Mounting, For Use With: 800 to 1200 A PG, PJ, PL, MG, MJ Frame Circuit Breaker, Aluminum
Specifications
Conductor Range |
3/0 AWG to 600 kcmil |
Material |
Aluminum |
Mounting Type |
Surface |
Suitable For Use With |
800 to 1200 A PG, PJ, PL, MG, MJ Frame Circuit Breaker |
Type |
3-Pole |
Standard Approval |
RoHS Compliant|CSA Certified|UL Listed|PROP65: This product can expose you to chemicals including: Lead and Lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov |
Application |
Cable Connection Applications |
