Schneider Electric ATV212HD22M3X
Schneider Electric Square D™ Altivar™ 212 ATV212HD22M3X 3-Phase Type 12 Variable Speed Drive, 200/240 VAC, 88 A, 30 hp, 9.45 in W x 8.43 in D
Brand: Schneider Electric
Item ID: 504724
MPN: ATV212HD22M3X
UPC: 785901921714
Login for Price
Features
- Without EMC filter
Description
The AHRI (Air-Conditioning, Heating, and Refrigeration Institute) certified Altivar™ 212 drive is for use with three-phase asynchronous and permanent magnet motors for variable torque pump, fan, and scroll compressor applications. Select the Altivar™ 212 drive using the motor nameplate voltage, the full load ampere rating and the table below. The Altivar™ 212 drive includes 3 logic inputs, 2 analog inputs, 1 analog output, and 2 relay outputs (with 1 NO and 1 NO/NC contacts). The Altivar™ 212 drive includes an integrated 4 digit, 7 segment LED display with a 7 button keypad and includes an RJ45 Modbus port plus a four-screw terminal block for BACnet, Modbus, Metasys N2 and Apogee P1 communication protocols. LonWorks™ is available in an option card.
Schneider Electric Square D™ Altivar™ 212 Variable Speed Drive, 3-Phase Type 12, Series: ATV212, 200/240 VAC, 88 A, 30 hp, 9.45 in Width, 8.43 in Depth, 16.54 in Height, IP20/IP21/IP41/Open Enclosure, Red LED Display
Specifications
Amperage Rating |
88 A |
Depth |
8.43 in |
Display Type |
Red LED |
Enclosure Type |
IP20/IP21/IP41/Open |
Height |
16.54 in |
Horsepower |
30 hp |
Series |
ATV212 |
Type |
3-Phase Type 12 |
Voltage Rating |
200/240 VAC |
Width |
9.45 in |
Standard Approval |
AHRI Certified|CSA Certified|CE Certified|C-Tick®|ECCN: EAR99|IEC 61000-4-2|IEC 61000-4-3|IEC 61000-4-4|IEC 61000-4-5|IEC 61000-4-6|IEC 61000-4-11|2 IEC 61800-5-1|EN/IEC 61800-5-1 IP20|EN/IEC 60529 IP20|IP21 EN/IEC 61800-5-1|IP21 EN/IEC 60529|IP41 EN/IEC 61800-5-1|IP41 EN/IEC 60529|EN/IEC 60068-2-6|EN/IEC 60068-2-8|IEC 60068-2-27|Classes 3C1 IEC 60721-3-3|Classes 3S2 IEC 60721-3-3|IEC 60068-2-3|IEC 60068-2-3|IEC 61800-3|EN 61800-3|EN 61800-3|EN 61800-5-1|EN 61800-3|EN 61800-3|IEC 61800-3|EN 61800-3|IEC 61800-3|IEC 61800-3|EN 61800-3|IEC 61800-3|IEC 61800-5-1|IEC 61800-3|IEC 61800-3|EN 61800-3|NOM 117|UL 1995|RoHS Compliant|REACH Compliant|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65PROP65s.ca.gov |
Application |
For asynchronous motor, pumps and fans in HVAC |
