Schneider Electric EZM1800GCBU
Square D™ EZ Meter-Pak™ EZM1800GCBU 3-Wire Underground Main Circuit Breaker Meter Center, 120/240 VAC, 800 A, 1 Phase
Brand: Schneider Electric
Item ID: 449477
MPN: EZM1800GCBU
UPC: 785901821861
Login for Price
Features
- Aluminum horizontal cross busbar upto 1000 A maximum
Description
Square D™ EZ Meter-Pak™ Main Circuit Breaker Meter Center, 3-Wire Underground, Series: EZM, 120/240 VAC, 800 A, 1, 65 kA Interrupt, 2 Pole, NEMA 3R, Lug, Steel, 53.97 in H x 18.66 in W x 11.5 in D
Specifications
Amperage Rating |
800 A |
Connection Type |
Lug |
Dimensions |
53.97 in H x 18.66 in W x 11.5 in D |
Enclosure Type |
NEMA 3R |
Interrupt Rating |
65 kA |
Material |
Steel |
Number of Poles |
2 |
Phase |
1 |
Series |
EZM |
Type |
3-Wire Underground |
Voltage Rating |
120/240 VAC |
Standard Approval |
UL Listed|PROP65: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
Application |
Indoor Applications |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_ACPA_Catalog.pdf
Full Engineering Drawing https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_EZM1800GCBU_Technical_Drawing_1.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_EZM11000CB_Installation_Sheet.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_EZM1800GCBU_Datasheet.pdf
