Square D™ EZML115125
Square D™ EZ Meter-Pak™ EZML115125 Lever Bypass Meter Center Branch Unit, 125 A, 120/240 VAC, 800 A Bus
Brand: Square D™
Item ID: 513420
MPN: EZML115125
UPC: 785901068150
Login for Price
Features
- Aluminum horizontal cross bus bar
Description
Square D™ EZ Meter-Pak™ Meter Center Branch Unit, Lever Bypass, 120/240 VAC, 800 A Bus, 125 A Socket, 5 Meter Sockets, 1 ph, Ringless Socket Cover Style, 5 With Jaw Release Socket Jaws, NEMA 3R Enclosure, Surface Mounting, 15.38 in W x 8.95 in D x 65 in H Dimensions
Specifications
Bus Amps |
800 A |
Dimensions |
15.38 in W x 8.95 in D x 65 in H |
Enclosure Type |
NEMA 3R |
Mounting Type |
Surface |
Number of Meter Sockets |
5 |
Phase |
1 ph |
Socket Amps |
125 A |
Socket Cover Style |
Ringless |
Socket Jaws |
5 With Jaw Release |
Type |
Lever Bypass |
Voltage Rating |
120/240 VAC |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_7adcf273fb76eb04ac3d80902d747187d127f6a90ca0368094a53d74a423a309.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b3c80d080e4e3f9c261520e44d083831d9eefa5c6bcf9d70ec12ffd33715481a.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_HJL36150CU43X_RoHS.pdf
Specification Sheet 3 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_944c1c9ef70f7564c639668627224d478d8825f74f761d3b4145482d9544bca7.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_ee387dbffaed64b785dcf5d3890494c58169dfa4a63e82451a1a304f9608bff6.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_EZML115125_Specification_Sheet.pdf
