Square D™ H228AWK
Square D™ H228AWK E4 Dust-Tight Driptight Fusible Rainproof Heavy Duty Safety Switch, 240/250 VAC/VDC, 1200 A, 50 hp, DPST Contact, 2 Poles
Brand: Square D™
Item ID: 471580
MPN: H228AWK
UPC: 785901637066
Login for Price
Features
- Visible blades for positive indication that switch is "OFF"
- Quick make, quick break operating mechanism
- Optional viewing window allows visual verification of blade position without opening door
- Red and black handle indicates the ON (red)/OFF (black) condition of the switch
- Dual cover interlock prevents the cover from being opened when the switch is ON and prevents the switch from being turned ON when the cover is open
- Handle lock-off provision for multiple padlocks "OFF" position
- Cover can be padlock closed
- Tangential knockouts, where provided, lessen the need for conduit offset bends
- Without knockouts
Description
The Square D™ by Schneider Electric brand heavy duty safety switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions, from commercial and institutional to industrial and manufacturing facilities.
Square D™ Heavy Duty Safety Switch, Dust-Tight Driptight Fusible Rainproof, Series: E4, 240/250 VAC/VDC, 1200 A, 50 hp, 1/2/3, 2 Pole, 2 Wires, 200 kA Short Circuit Current, DPST, Handle Actuator, NEMA 12, Surface Mount, Lug Terminal, -22 to 104 deg F, 69.13 in H x 36.62 in W x 17.75 in D, Steel, Gray, Galvannealed/Painted
Specifications
Actuator Type |
Handle |
Amperage Rating |
1200 A |
Color |
Gray |
Contact Form |
DPST |
Dimensions |
69.13 in H x 36.62 in W x 17.75 in D |
Enclosure Type |
NEMA 12 |
Finish |
Galvannealed/Painted |
Horsepower |
50 hp |
Material |
Steel |
Mounting Type |
Surface |
Number of Poles |
2 |
Number of Wires |
2 |
Phase |
1/2/3 |
Series |
E4 |
Short Circuit Current Rating |
200 kA |
Temperature Rating |
-22 to 104 deg F |
Terminal Type |
Lug |
Type |
Dust-Tight Driptight Fusible Rainproof |
Voltage Rating |
240/250 VAC/VDC |
Standard Approval |
Federal Specification WS-865C|UL 98 File No. E154828|PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65Warnings.ca.gov |
Application |
Mining, Mineral, Commercial Buildings, Manufacturing, Industrial Buildings, Water Wastewater, Healthcare Facilities, Educational Campuses and Indoor/Outdoor Applications |
