Square D™ HL2IMA12C
Square D™ Surgelogic™ HL2IMA12C IMA Series HL/Retrofit Surge Protective Device, 208Y/120 VAC, 3 Poles, 200 kA SCCR, 3 ph Phase
Brand: Square D™
Item ID: 543440
MPN: HL2IMA12C
UPC: 785901642459
Login for Price
Features
- Audible alarm with enable/disable switch, dry contacts and surge counter standard
- EMI/RFI filtering
Description
To ensure high-performance surge suppression at critical power locations, a variety of Surgelogic™ products have been designed specifically for retrofitting into commonly used Square D™ systems. The QMB fusible switch, 6 in. MCC bucket, I-Line and Busway plug-on units and the SurgeLoc for the NQ panelboards come ready to install. Retrofitting SPD units into I-Line, QMB, MCC, Busway and NQ Panelborad applications is simple.
Square D™ Surgelogic™ Surge Protective Device, HL/Retrofit, Series: IMA Series, 208Y/120 VAC, 3 Pole, 4 Wires, 200 kA Short Circuit Current, 120 kA Peak Surge, Alarm/LED Status Light Indicator, 3 ph, NEMA 2, Panel Mount, Lug Terminal, 341.9 mm W x 142.1 mm D x 308.9 mm H
Specifications
Dimensions |
341.9 mm W x 142.1 mm D x 308.9 mm H |
Electrical Ratings |
208Y/120 VAC |
Enclosure Type |
NEMA 2 |
Indicator Type |
Alarm/LED Status Light |
Mounting Type |
Panel |
Number of Poles |
3 |
Number of Wires |
4 |
Peak Surge Current |
120 kA |
Phase |
3 ph |
Series |
IMA Series |
Short Circuit Current Rating |
200 kA |
Terminal Type |
Lug |
Type |
HL/Retrofit |
Standard Approval |
CSA C22.2 File No. 5-09/NO 8:1986|UL 1449|ECCN: EAR99|PROP65: This product can expose you to chemicals including: Lead and lead compounds which is known to the State of California to cause Carcinogen and Reproductive harm. For more information go to www.p65warnings.ca.gov |
