Square D™ Homeline™ HOM115PDF Dual Function Combination Miniature Circuit Breaker, 120 VAC, 15 A, 10 kA Interrupt, 1 Pole, Thermal Magnetic Trip
Brand: Square D™
Item ID: 427595
MPN: HOM115PDF
Login for Price
Features
- Dual function - combination arc fault and ground fault class A 6 mA
- HACR rated
- Al/Cu wire
- Plug-on neutral mounting mode
Description
Square D™ Homeline™ Combination Miniature Circuit Breaker, Dual Function, 120 VAC, 15 A, 50/60 Hz Frequency, 10 kA Interrupt, Thermal Magnetic Trip, 1 Pole, 1 ph, Clamp Connection, 14 to 8/14 to 10 AWG Wire, NEMA 1/2 Enclosure, Plug-In Mounting, 40 deg C, 2.98 in L x 1 in W x 3.13 in H Dimensions
Specifications
Amperage Rating |
15 A |
Connection Type |
Clamp |
Dimensions |
2.98 in L x 1 in W x 3.13 in H |
Enclosure Type |
NEMA 1/2 |
Frequency Rating |
50/60 Hz |
Interrupt Rating |
10 kA |
Mounting Type |
Plug-In |
Number of Poles |
1 |
Phase |
1 ph |
Temperature Rating |
40 deg C |
Trip Type |
Thermal Magnetic |
Type |
Dual Function |
Voltage Rating |
120 VAC |
Wire Size |
14 to 8/14 to 10 AWG |
Standard Approval |
Buy American Act Compliant|CSA Certified|Federal Specifications WP115B|NEMA Compliant|RoHS Compliant|UL File No. E6294|PROP65: Cancer and Reproductive harm - www.P65warnings.ca.gov |
Application |
For AC systems and providing overload and short circuit protection |
