Square D™ HOM1224L125PC
Square D™ Homeline™ HOM1224L125PC 1-ph Convertible Main Lug Loadcenter, 120/240 VAC, 125 A, 1 Pole, 22 kA Interrupt
Brand: Square D™
Item ID: 427386
MPN: HOM1224L125PC
UPC: 785901876120
Login for Price
Features
- Tin plated aluminum bus construction on main lug or main circuit breaker panels
- Service entrance equipment capable panels
- Straight in wiring to help minimize service cable installations
- Single captive screw interior mounting on indoor panels to ease removal
- New side hinge doors on outdoor convertible main panels
- Outdoor panel covers are lockable with padlock
- Gray baked enamel electrodeposited over cleaned, phosphatized steel
- Top or bottom feed by rotating enclosure
- Plug-on neutral circuit breaker
- Lug electrical connection
- 12 tandem circuit breaker
Description
Homeline™ circuit breaker load centers from Square D™ are UL Listed panel boards. They are designed to meet residential, commercial and industrial requirements to protect electrical systems, equipment and people.
Square D™ Homeline™ Main Lug Loadcenter, 1-ph Convertible, 120/240 VAC, 125 A, 1 Pole, 50/60 Hz, 22 kA Interrupt, 24 Circuits, HOM Breaker, Panel Breaker Mounting, 3-Wire Wiring Configuration, 12 Spaces, 6 to 2/0 AWG Wire, Flush Mount, NEMA 1, Steel Housing, 14.25 in W x 3.75 in D x 17.92 in H
Specifications
Amperage Rating |
125 A |
Breaker Mounting |
Panel |
Breaker Type |
HOM |
Dimensions |
14.25 in W x 3.75 in D x 17.92 in H |
Enclosure Type |
NEMA 1 |
Frequency Rating |
50/60 Hz |
Housing Material |
Steel |
Interrupt Rating |
22 kA |
Mounting Type |
Flush |
Number of Circuits |
24 |
Number of Poles |
1 |
Number of Spaces |
12 |
Type |
1-ph Convertible |
Voltage Rating |
120/240 VAC |
Wire Size |
6 to 2/0 AWG |
Wiring Configuration |
3-Wire |
Standard Approval |
RoHS Compliant|UL File No. E6294|PROP65: This product can expose you to chemicals including: Lead and Lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov |
Application |
Residential, Commercial and Industrial Applications |
