Schneider Electric LC1D258G7
Schneider Electric Square D™ TeSys™ D LC1D258G7 Standard IEC Contactor, 120/690 VDC, 300 VDC V Coil, 40 A, 2NO-2NC Contact, 4 Poles
Brand: Schneider Electric
Item ID: 392070
MPN: LC1D258G7
UPC: 785901503149
Login for Price
Features
- Without built-in bi-directional peak limiting diode suppressor coil technology
- 40 A at 60 deg C for power circuit and 10 A at 60 deg C for signaling circuit
Description
Schneider Electric Square D™ TeSys™ D IEC Contactor, Standard, Series: LC1D, 120/690 VDC, 300 VDC Coil, 40 A Maximum Load Current, 7.5/7.7 VA Coil, 4 Pole, 50/60 Hz Frequency, 3.2 W Wattage, Non-Reversing Contact, 2NO-2NC Contact Configuration, 1NO-1NC Auxiliary Contacts, 10/60 A at 600 VAC, 40/60 at 600 VAC Contact, Power Factor: 0.75 Inrush, 0.3 Hold-In, Screw Clamp Connection, 105/45/99 mm Size, Screw Clamp Terminal, IP2X Enclosure, 3600 cycles/hr Operating Cycles, -5 to 60/-40 to 70 deg C Operating, Rail/Surface Mounting, 45 mm W x 99 mm D x 105 mm H Dimensions
Specifications
Coil Power Rating |
7.5/7.7 VA |
Coil Voltage |
120/690 VDC, 300 VDC |
Connection Type |
Screw Clamp |
Contact Configuration |
2NO-2NC |
Contact Rating |
10/60 A at 600 VAC, 40/60 at 600 VAC |
Contact Type |
Non-Reversing |
Dimensions |
45 mm W x 99 mm D x 105 mm H |
Enclosure Type |
IP2X |
Frequency Rating |
50/60 Hz |
Maximum Load Current |
40 A |
Mounting Type |
Rail/Surface |
Number of Auxiliary Contacts |
1NO-1NC |
Number of Poles |
4 |
Operating Cycles |
3600 cycles/hr |
Operating Temperature |
-5 to 60/-40 to 70 deg C |
Power Factor |
0.75 Inrush, 0.3 Hold-In |
Series |
LC1D |
Size |
105/45/99 mm |
Terminal Type |
Screw Clamp |
Type |
Standard |
Wattage |
3.2 W |
Standard Approval |
BV/CCC/DNV (Det Norske Veritas)/GL/GOST/LROS/RINA Certifications|CE Certified|CSA 3211 04|CSA C22.2 No.LR43364|EN 60947-4-1/EN 60947-5-1|File File No. E164862 NLDX|IEC 60529/VDE 0106|IEC 60647-4|IEC 60947-4-1/60947-5-1|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65warnings.ca.gov|RoHS Compliant|UL 508 |
Application |
Resistive Load Applications |
